Huber+Suhner 85177130 RF AttenuatorStraight 7 dBMaleFemale
- RS Stock No.:
- 274-2073
- Distrelec Article No.:
- 303-73-140
- Mfr. Part No.:
- 85177130
- Brand:
- Huber+Suhner
Bulk discount available
Subtotal (1 unit)*
£70.82
(exc. VAT)
£84.98
(inc. VAT)
Add 1 unit to get free delivery
Temporarily out of stock
- 33 unit(s) shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 1 | £70.82 |
| 2 - 2 | £67.99 |
| 3 - 4 | £65.37 |
| 5 - 9 | £62.96 |
| 10 + | £60.69 |
*price indicative
- RS Stock No.:
- 274-2073
- Distrelec Article No.:
- 303-73-140
- Mfr. Part No.:
- 85177130
- Brand:
- Huber+Suhner
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Huber+Suhner | |
| Interface Type | Type N | |
| Product Type | RF Attenuator | |
| Impedance | 50Ω | |
| Maximum Frequency | 6GHz | |
| Body Plating | Metal | |
| Contact Plating | Gold Plated | |
| Contact Material | Beryllium Copper Alloy | |
| Low Power | Yes | |
| Connector Type | Coaxial | |
| Minimum Operating Temperature | -55°C | |
| Maximum Attenuation | 7dB | |
| Orientation | Straight | |
| Maximum Operating Temperature | 125°C | |
| Connector Gender A | Male | |
| Standards/Approvals | No | |
| Connector Gender B | Female | |
| Series | 6807_N-50-1/1--_N | |
| Select all | ||
|---|---|---|
Brand Huber+Suhner | ||
Interface Type Type N | ||
Product Type RF Attenuator | ||
Impedance 50Ω | ||
Maximum Frequency 6GHz | ||
Body Plating Metal | ||
Contact Plating Gold Plated | ||
Contact Material Beryllium Copper Alloy | ||
Low Power Yes | ||
Connector Type Coaxial | ||
Minimum Operating Temperature -55°C | ||
Maximum Attenuation 7dB | ||
Orientation Straight | ||
Maximum Operating Temperature 125°C | ||
Connector Gender A Male | ||
Standards/Approvals No | ||
Connector Gender B Female | ||
Series 6807_N-50-1/1--_N | ||
- COO (Country of Origin):
- CN
The Huber & Suhner RF Attenuator is a low power standard type attenuator. This RF attenuator constructed with male and female type connector. It has N plug connection at one side and N jack connection at second side.
RoHS compliant
7 dB nominal attenuation
50 ohm nominal impedance
DC to 6 GHz frequency range
