Sensata / Cynergy3 PCB Reed Relay, 5 V dc Coil, SPST, 1000 V dc Max, 1 A Max, 120 Ω
- RS Stock No.:
- 124-5063
- Mfr. Part No.:
- S8-0504V/RS
- Brand:
- Sensata / Cynergy3
Bulk discount available
Subtotal (1 unit)*
£15.92
(exc. VAT)
£19.10
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 20 unit(s) shipping from 28 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 24 | £15.92 |
| 25 - 49 | £15.10 |
| 50 - 99 | £14.35 |
| 100 - 249 | £13.64 |
| 250 + | £12.96 |
*price indicative
- RS Stock No.:
- 124-5063
- Mfr. Part No.:
- S8-0504V/RS
- Brand:
- Sensata / Cynergy3
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sensata / Cynergy3 | |
| Contact Configuration | SPST | |
| Product Type | Reed Relay | |
| Mount Type | PCB | |
| Coil Power | 100VA | |
| Terminal Type | PCB Terminal | |
| Coil Resistance | 120Ω | |
| Minimum Operating Temperature | -40°C | |
| Switching Power | 100VA | |
| Operating Time | 1ms | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | UR | |
| Series | S8 | |
| Length | 30mm | |
| Height | 12mm | |
| Isolation Coil To Contact | 7kV | |
| Contact Resistance | 150mΩ | |
| Latching | No | |
| Select all | ||
|---|---|---|
Brand Sensata / Cynergy3 | ||
Contact Configuration SPST | ||
Product Type Reed Relay | ||
Mount Type PCB | ||
Coil Power 100VA | ||
Terminal Type PCB Terminal | ||
Coil Resistance 120Ω | ||
Minimum Operating Temperature -40°C | ||
Switching Power 100VA | ||
Operating Time 1ms | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals UR | ||
Series S8 | ||
Length 30mm | ||
Height 12mm | ||
Isolation Coil To Contact 7kV | ||
Contact Resistance 150mΩ | ||
Latching No | ||
- COO (Country of Origin):
- GB
Sensata Cynergy3 Reed Relay, 5V DC Coil Voltage, 1A Switching Current - S8 Relay Series - S8-0504V/RS
Use this general-purpose relay from Sensata Cynergy3 to control reed switches on automated systems. This component works by creating a magnetic field close to the switch contacts to trigger a reaction on the equipment it's connected to. Its contacts are made of a rhodium material that's highly conductive and has low electrical resistance, ensuring a reliable connection. This device has a long mechanical service life of 1,000,000,000 operations in dry switching conditions, so it will last a long time. It's commonly used in industrial and commercial alarm systems to sense when doors are open or closed.
Features & Benefits
• Wide operating temperature range of -40ºC to +85ºC for use in demanding environments
• Nylon case material for resistance to impact and insulation from electric shock
• Compact dimensions of 30 (length) x 10 (depth) x 12mm (height) for use in tight spaces
• Isolation between the contacts and coil for improved electrical safety
What's the operating time of this reed relay?
This reed relay has a fast operating time of just 1ms to ensure speedy switching.
