Europa EUR1 Series Residual Current Circuit Breaker, 25A, 2-Pole, 30 mA, Type A, 10 kA 415V ac
- RS Stock No.:
- 210-4747
- Mfr. Part No.:
- EUR125.30/2A
- Brand:
- Europa
Subtotal (1 unit)*
£42.60
(exc. VAT)
£51.12
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 51 unit(s) ready to ship
- Plus 25 unit(s) shipping from 23 June 2026
- Plus 25 unit(s) shipping from 04 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £42.60 |
*price indicative
- RS Stock No.:
- 210-4747
- Mfr. Part No.:
- EUR125.30/2A
- Brand:
- Europa
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Europa | |
| Product Type | Residual Current Circuit Breaker | |
| Current Rating | 25A | |
| Number of Poles | 2 | |
| Range | EUR1 | |
| Series | EUR1 | |
| Trip Sensitivity | 30mA | |
| Tripping Characteristics | Type A | |
| Mount Type | DIN Rail | |
| Terminal Type | Tunnel | |
| Standards/Approvals | IEC 61008, EN 61008 | |
| Height | 76mm | |
| Depth | 89mm | |
| Breaking Capacity | 10kA | |
| Tripping Mechanism | Electromagnetic | |
| Earth Leakage Protection Type | Type A | |
| Rated AC Voltage | 415V ac | |
| Reset Actuator Type | Toggle Switch | |
| Select all | ||
|---|---|---|
Brand Europa | ||
Product Type Residual Current Circuit Breaker | ||
Current Rating 25A | ||
Number of Poles 2 | ||
Range EUR1 | ||
Series EUR1 | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type A | ||
Mount Type DIN Rail | ||
Terminal Type Tunnel | ||
Standards/Approvals IEC 61008, EN 61008 | ||
Height 76mm | ||
Depth 89mm | ||
Breaking Capacity 10kA | ||
Tripping Mechanism Electromagnetic | ||
Earth Leakage Protection Type Type A | ||
Rated AC Voltage 415V ac | ||
Reset Actuator Type Toggle Switch | ||
- COO (Country of Origin):
- CN
The Europa EUR1 series Type A RCCB has rated current of 25A and rated residual operating current of 30mA. It has 2 poles and rated short circuit capacity of 10kA.
Can be fitted upstream of a Type A or Type AC RCCB device
Type A is also suitable for Type AC applications resulting to wider range of installations which the RCCB can be used in
Suitable for electric vehicle charging where any smooth DC fault current is less than 6mA
