Eaton RCCB, 63A, 3+N Pole, 300mA, Type B
- RS Stock No.:
- 183-3559
- Mfr. Part No.:
- 167910 FRCDM-63/4/03-S/BFQ
- Brand:
- Eaton
Subtotal (1 unit)*
£1,538.07
(exc. VAT)
£1,845.68
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,538.07 |
*price indicative
- RS Stock No.:
- 183-3559
- Mfr. Part No.:
- 167910 FRCDM-63/4/03-S/BFQ
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Circuit Breaker Type | RCCB | |
| Current Rating | 63A | |
| Number of Poles | 3+N | |
| Range | FRCdM | |
| Trip Sensitivity | 300mA | |
| Tripping Characteristics | Type B | |
| Overall Length | 70mm | |
| Break Time | Time Delay | |
| Mounting Style | DIN Rail Mount | |
| Rated DC Voltage | 220V | |
| Rated AC Voltage | 240V | |
| Breaking Capacity at Maximum Voltage Rating | 630 A | |
| Overall Width | 76mm | |
| Terminal Contact Type | Screw | |
| Overall Dimensions | 70 x 76 x 80mm | |
| Overall Depth | 80mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Circuit Breaker Type RCCB | ||
Current Rating 63A | ||
Number of Poles 3+N | ||
Range FRCdM | ||
Trip Sensitivity 300mA | ||
Tripping Characteristics Type B | ||
Overall Length 70mm | ||
Break Time Time Delay | ||
Mounting Style DIN Rail Mount | ||
Rated DC Voltage 220V | ||
Rated AC Voltage 240V | ||
Breaking Capacity at Maximum Voltage Rating 630 A | ||
Overall Width 76mm | ||
Terminal Contact Type Screw | ||
Overall Dimensions 70 x 76 x 80mm | ||
Overall Depth 80mm | ||
- COO (Country of Origin):
- CZ
Digital residual current circuit-breaker, 63A, 4p, 300mA, type S/BFQ
All-current sensitive RCCB for fault or additional protection
Digital Features
System Monitoring: Preventive information / warning before the RCD trips in case of leakage currents
Integrated auxiliary contact
Local Indication through 3 LEDs
4-pole types can also be used as 2-pole devices for photovoltaic applications
New level of accuracy -> reduced unwanted tripping
No monthly test required
Comprehensive range of accessories
Real contact position indicator
Fault current tripping indicator
Automatic re-setting possible
Transparent designation plate
Digital Features
System Monitoring: Preventive information / warning before the RCD trips in case of leakage currents
Integrated auxiliary contact
Local Indication through 3 LEDs
4-pole types can also be used as 2-pole devices for photovoltaic applications
New level of accuracy -> reduced unwanted tripping
No monthly test required
Comprehensive range of accessories
Real contact position indicator
Fault current tripping indicator
Automatic re-setting possible
Transparent designation plate
Note
Eaton formerly known as Moeller
