ABB RCBO, 10A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, System Pro M Compact Range
- RS Stock No.:
- 181-4382
- Mfr. Part No.:
- DS-ARC1 M C10 A30
- Brand:
- ABB
Subtotal (1 unit)**
£268.20
(exc. VAT)
£321.84
(inc. VAT)
Available to back order for despatch 05/05/2025*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over £50.00
Units | Per unit |
---|---|
1 + | £268.20 |
**price indicative
- RS Stock No.:
- 181-4382
- Mfr. Part No.:
- DS-ARC1 M C10 A30
- Brand:
- ABB
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ABB | |
Current Rating | 10A | |
Number of Poles | 1P+N | |
Trip Sensitivity | 30mA | |
Tripping Characteristics | Type C | |
Range | System Pro M Compact | |
Circuit Breaker Type | RCBO | |
Series | DS-ARC1 | |
Rated AC Voltage | 230 → 240V | |
Mounting Style | DIN Rail Mount | |
Earth Leakage Protection Type | A | |
Breaking Capacity at Maximum Voltage Rating | 10 kA | |
Reset Actuator Type | Toggle Switch | |
Overall Dimensions | 52.2 x 69 x 85mm | |
Overall Length | 52.2mm | |
Overall Width | 69mm | |
Overall Depth | 85mm | |
Select all | ||
---|---|---|
Brand ABB | ||
Current Rating 10A | ||
Number of Poles 1P+N | ||
Trip Sensitivity 30mA | ||
Tripping Characteristics Type C | ||
Range System Pro M Compact | ||
Circuit Breaker Type RCBO | ||
Series DS-ARC1 | ||
Rated AC Voltage 230 → 240V | ||
Mounting Style DIN Rail Mount | ||
Earth Leakage Protection Type A | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Reset Actuator Type Toggle Switch | ||
Overall Dimensions 52.2 x 69 x 85mm | ||
Overall Length 52.2mm | ||
Overall Width 69mm | ||
Overall Depth 85mm | ||
