ABB RCBO, 6A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, System Pro M Compact Range
- RS Stock No.:
- 181-4381
- Mfr. Part No.:
- DS-ARC1 M C6 A30
- Brand:
- ABB
Available to back order for despatch 11/09/2024
Price Each
£223.50
(exc. VAT)
£268.20
(inc. VAT)
Units | Per unit |
|---|---|
| 1 - 4 | £223.50 |
| 5 - 9 | £212.32 |
| 10 - 24 | £201.16 |
| 25 - 49 | £189.96 |
| 50 + | £178.81 |
- RS Stock No.:
- 181-4381
- Mfr. Part No.:
- DS-ARC1 M C6 A30
- Brand:
- ABB
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
DS-ARC1 is the new 1P+N AFDD with an integrated residual current circuit breaker with overcurrent protection (RCBO) in 6 kA and 10 kA breaking capacity. In only three-module width, DS-ARC1 series offers a complete protection against arc faults overvoltages, overcurrent, earth fault currents.
Easy cross-wiring and easy installation with System pro M compact® busbars without any extra cables
Supply possible both from top and bottom side: double slots available for connection with cables and busbars
Family feeling in the System pro M compact® range
Compatible with System pro M compact® accessories
LED for an easy troubleshooting of the network
Two test button to verify the correct working conditions of AFDD and RCD
Continuous internal self-test
Supply possible both from top and bottom side: double slots available for connection with cables and busbars
Family feeling in the System pro M compact® range
Compatible with System pro M compact® accessories
LED for an easy troubleshooting of the network
Two test button to verify the correct working conditions of AFDD and RCD
Continuous internal self-test
Specifications
Attribute | Value |
|---|---|
| Current Rating | 6A |
| Number of Poles | 1P+N |
| Trip Sensitivity | 30mA |
| Tripping Characteristics | Type C |
| Range | System Pro M Compact |
| Circuit Breaker Type | RCBO |
| Series | DS-ARC1 |
| Rated AC Voltage | 230 → 240V |
| Mounting Style | DIN Rail Mount |
| Earth Leakage Protection Type | A |
| Overall Width | 69mm |
| Overall Depth | 85mm |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Overall Length | 52.2mm |
| Overall Dimensions | 52.2 x 69 x 85mm |
| Reset Actuator Type | Toggle Switch |
