ITW Switches 48 Series Illuminated Push Button Switch, Momentary, Panel Mount, 13.6mm Cutout, SPST, Red LED, 48V dc,
- RS Stock No.:
- 173-8556
- Mfr. Part No.:
- 48-1-RB-R-GR-B
- Brand:
- ITW Switches
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 173-8556
- Mfr. Part No.:
- 48-1-RB-R-GR-B
- Brand:
- ITW Switches
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ITW Switches | |
Switch Operation | Momentary | |
Illuminated | Yes | |
Panel Cut Out Diameter | 13.6mm | |
Series | 48 | |
Mounting Type | Panel Mount | |
Push Button Colour | Green | |
Contact Configuration | SPST | |
Voltage Rating | 48V dc | |
Push Button Style | Round | |
LED Colour | Red | |
IP Rating | IP67 | |
Contact Current Rating | 250 mA @ 12 V dc | |
Contact Material | Gold Plated | |
Manufacturer Part No. | 48-1-RB-R-GR-B | |
Contact DC Voltage Rating | 12V | |
Case Colour | Black | |
Maximum Operating Temperature | +85°C | |
Terminal Type | Solder | |
Minimum Operating Temperature | -40°C | |
Operating Temperature Range | -40 → +85°C | |
Select all | ||
---|---|---|
Brand ITW Switches | ||
Switch Operation Momentary | ||
Illuminated Yes | ||
Panel Cut Out Diameter 13.6mm | ||
Series 48 | ||
Mounting Type Panel Mount | ||
Push Button Colour Green | ||
Contact Configuration SPST | ||
Voltage Rating 48V dc | ||
Push Button Style Round | ||
LED Colour Red | ||
IP Rating IP67 | ||
Contact Current Rating 250 mA @ 12 V dc | ||
Contact Material Gold Plated | ||
Manufacturer Part No. 48-1-RB-R-GR-B | ||
Contact DC Voltage Rating 12V | ||
Case Colour Black | ||
Maximum Operating Temperature +85°C | ||
Terminal Type Solder | ||
Minimum Operating Temperature -40°C | ||
Operating Temperature Range -40 → +85°C | ||
- COO (Country of Origin):
- TW
48 Series IP67 Sealed
Rugged sealed pushbutton switches with various options of termination type and LED illumination.
Long-life (100,000 ops) gold-plated SPNO contacts
Rating 250mA @ 12Vdc, 100mA 48Vdc
IP67 panel sealing
17.4mm diameter, 13.6mm panel mounting cut-out
Suitable for panel thickness of 0.5 to 3.0mm
Rating 250mA @ 12Vdc, 100mA 48Vdc
IP67 panel sealing
17.4mm diameter, 13.6mm panel mounting cut-out
Suitable for panel thickness of 0.5 to 3.0mm
ITW Push Button Switch
The ITW 48 series electromechanical 1-pole on-off push button switch. It is a panel-sealed push button switch with centre-spot and ring-style LED illumination options. The switching current rate is up to 250mA. It is designed to easily mount into the panels with a thickness range of 0.5mm to 3.0mm. It supports momentary switch operation with a red LED.
Features and Benefits
• Ease to use
• Gold is used as contact material
• Long life up to 100,000 life cycles
• Operating temperature ranges between -40°C and 85°C
• Panel type mounting
• Rugged construction with panel sealing
• Voltage rating is 12VDC
• Gold is used as contact material
• Long life up to 100,000 life cycles
• Operating temperature ranges between -40°C and 85°C
• Panel type mounting
• Rugged construction with panel sealing
• Voltage rating is 12VDC
Applications
• Food processing equipment
• Industrial machinery
• Medical equipment
• Military equipment
• Outdoor controls
• Security equipment
• Transportation equipment
• Industrial machinery
• Medical equipment
• Military equipment
• Outdoor controls
• Security equipment
• Transportation equipment
Certifications
• IP67 rating
ITW Sealed
