Carlo Gavazzi CA30CAF16PA Threaded Barrel Capacitive Proximity Sensor CA30CAF 16 mm, M30 PNP, PNP NO/NC 200mA 40V dc 40
- RS Stock No.:
- 283-6799
- Mfr. Part No.:
- CA30CAF16PA
- Brand:
- Carlo Gavazzi
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£66.52
(exc. VAT)
£79.82
(inc. VAT)
- RS Stock No.:
- 283-6799
- Mfr. Part No.:
- CA30CAF16PA
- Brand:
- Carlo Gavazzi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Carlo Gavazzi | |
| Thread Size | M30 | |
| Product Type | Capacitive Proximity Sensor | |
| Body Style | Threaded Barrel | |
| IP Rating | IP69K, IP68, IP67 | |
| Length | 2m | |
| Terminal Type | Cable | |
| Mount Type | Flush | |
| Maximum Supply Voltage | 40V dc | |
| Housing Material | Glass Reinforced Nylon | |
| Minimum Operating Temperature | -40°C | |
| Materials Detected | Liquid, Solid | |
| Maximum DC Voltage | 40V dc | |
| Maximum Detection | 16mm | |
| Maximum Operating Temperature | 80°C | |
| Hazardous Area Certification | NO | |
| Standards/Approvals | cULus (UL508) | |
| Shielding | Shielded | |
| Series | CA30CAF | |
| Output Type | PNP, PNP NO/NC | |
| Switching Current | 200mA | |
| Maximum Switching Frequency | 50Hz | |
| Select all | ||
|---|---|---|
Brand Carlo Gavazzi | ||
Thread Size M30 | ||
Product Type Capacitive Proximity Sensor | ||
Body Style Threaded Barrel | ||
IP Rating IP69K, IP68, IP67 | ||
Length 2m | ||
Terminal Type Cable | ||
Mount Type Flush | ||
Maximum Supply Voltage 40V dc | ||
Housing Material Glass Reinforced Nylon | ||
Minimum Operating Temperature -40°C | ||
Materials Detected Liquid, Solid | ||
Maximum DC Voltage 40V dc | ||
Maximum Detection 16mm | ||
Maximum Operating Temperature 80°C | ||
Hazardous Area Certification NO | ||
Standards/Approvals cULus (UL508) | ||
Shielding Shielded | ||
Series CA30CAF | ||
Output Type PNP, PNP NO/NC | ||
Switching Current 200mA | ||
Maximum Switching Frequency 50Hz | ||
RoHS Status: Exempt
The capacitive proximity switch is a versatile and reliable solution for various industrial applications. With its 4 Generation TRIPLESHIELD technology, it offers adjustable sensing distances of 2 - 16 mm, flush mounting, and NPN output. The sensor is designed to withstand harsh environments, with IP67 and IP69K ratings, making it dust and waterproof. Its thermoplastic polyester housing ensures durability and protection against transients and reverse polarity. It features LED indications for power-supply, output, and stability, providing easy monitoring. It is suitable for use in the chemical, packaging, wood, ceramics, glass, and plastics industries.
Adjustable sensing distance 2 - 16 mm Flush
Protection against short-circuits, transients, and reverse polarity
Dust and humidity compensation for reliable operation
Dust or temperature alarm outputs for early warnings
Rated operational voltage 10-40 VDC
Output DC 200 mA, NPN
LED indications for Power-supply, Output, and Stability
IP67, IP69K ratings for dust and waterproofing
Durable thermoplastic polyester housing for longevity
Versatile applications in various industries
