SICK PBS2 Series Pressure Sensor, NPN/PNP Output 0 bar 16 bar, Gauge Reading

View all Pressure Sensors

Subtotal (1 unit)*

£340.15

(exc. VAT)

£408.18

(inc. VAT)

Add to Basket
Select or type quantity
Stocked by manufacturer
  • Ready to ship from 02 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£340.15

*price indicative

RS Stock No.:
285-2182
Mfr. Part No.:
PBS2-RB016SG2SS0Q5A0Z
Brand:
SICK
Find similar products by selecting one or more attributes.
Select all

Brand

SICK

Maximum Pressure Measurement

16bar

Pressure Reading Type

Gauge

Product Type

Pressure Sensor

Minimum Pressure Measurement

0bar

Accuracy

±0.5 %

Output Type

NPN/PNP

Media Measured

Gas, Liquid

Interface Type

PNP, IO-Link, NPN

Terminal Type

M12 Round Connector

Minimum Supply Voltage

15V

Response Time

5ms

Series

PBS2

Maximum Supply Voltage

35V dc

Standards/Approvals

EMC Directive:2014/30/EU (EN 61326-1:2013,EN 61326-2-3:2013), Hazardous Materials (RoHS):2011/65/EU (EN 50581:2012), Pressure equipment Directive:2014/68/EU

Housing Material

Thermoplastic Polyester Elastomer (Button), 304 Stainless Steel (Lower Body), Display Window: Polycarbonate, Plastic

IP Rating

IP67

Maximum Operating Temperature

85°C

Minimum Operating Temperature

-20°C

COO (Country of Origin):
DE

Overview


The PBS plus is an electronic pressure switch, pressure transmitter and display in one and is available with up to two switching outputs, analogue output and IO-Link. It is set using three large pushbuttons and the display or via IO-Link. The housing can be twisted in two places - the display and the electrical connection can be optimally aligned in any mounting situation. With measuring ranges of 0.4 bar to 1,000 bar (gauge pressure), the PBS plus can be used in many different applications. It also has absolute pressure and vacuum measuring ranges.

The PBS plus is highly resistant to corrosion due to the fully welded stainless steel membrane. Process data is transmitted to the control via IO-Link as measured values in bar. The diagnostic options make it possible for temperature values to be read out in °C and minimum and maximum values for temperature and pressure to be monitored.

At a glance


Switchable switching outputs (PNP/NPN) and analogue output (current/voltage)

Scalable analogue output (5:1 turn down)

High measurement accuracy: ± 0.5%

IO-Link for transmitting process data to the control as measured values in bar

Housing can be twisted in two places (process connection/display) and display can be rotated by 180°

Common process connections, also with flush-mounted membrane

Your Benefit


Low storage costs, short delivery times, low number of variants

Reduced installation time since housing and display can be rotated at two points

Rugged design: stainless steel measuring cell

No special conversion of IO-Link process data is required - it is shown automatically as measured values in bar

Extensive diagnosis options via IO-Link (e.g. pressure peaks, ambient temperature) deliver data for predictive maintenance

Economic solution for hydrostatic level measurement (thanks to high accuracy and small measuring ranges)

Applications


Factory automation applications:

Monitoring the media supply using pressure measurement

Pressure measurement in the hydraulic system

Measuring pressure, level, and temperature in the machine hydraulics

Monitoring of the pressure in the cylinder

Monitoring
