TE Connectivity MEAS M5200 Series Pressure Sensor, 0bar Min, 16bar Max, Gauge Reading
- RS Stock No.:
- 261-8129
- Mfr. Part No.:
- M5256-00000E-016BG
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 unit)*
£168.28
(exc. VAT)
£201.94
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 6 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £168.28 |
5 - 9 | £149.61 |
10 - 19 | £140.23 |
20 + | £135.56 |
*price indicative
- RS Stock No.:
- 261-8129
- Mfr. Part No.:
- M5256-00000E-016BG
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TE Connectivity | |
Pressure Reading Type | Gauge | |
Minimum Pressure Reading | 0bar | |
Maximum Pressure Reading | 16bar | |
Accuracy | ±0.25 % | |
Media Measured | Gas, Liquid | |
Analogue Output | 4 → 20 mA | |
Electrical Connection | Form C Without Mating Connector | |
Series | MEAS M5200 | |
Supply Voltage | 9 → 30 V | |
Maximum Operating Temperature | +125°C | |
Minimum Operating Temperature | -40°C | |
Select all | ||
---|---|---|
Brand TE Connectivity | ||
Pressure Reading Type Gauge | ||
Minimum Pressure Reading 0bar | ||
Maximum Pressure Reading 16bar | ||
Accuracy ±0.25 % | ||
Media Measured Gas, Liquid | ||
Analogue Output 4 → 20 mA | ||
Electrical Connection Form C Without Mating Connector | ||
Series MEAS M5200 | ||
Supply Voltage 9 → 30 V | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- CN
The TE Connectivity industrial pressure transducer is suitable for measurement of liquid or gas pressure, even for difficult media such as contaminated water, steam, and mildly corrosive fluids. This product is geared to the OEM customer for low to mid volumes.
Reverse polarity protection on input
Weatherproof
Weatherproof
