TE Connectivity PCB Mount Power Relay, 24V dc Coil, 16A Switching Current, SPST
- RS Stock No.:
- 909-7915
- Mfr. Part No.:
- 2-1440002-9
- Brand:
- TE Connectivity
Subtotal (1 unit)**
£2.95
(exc. VAT)
£3.54
(inc. VAT)
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over £50.00
Units | Per unit |
|---|---|
| 1 - 9 | £2.95 |
| 10 - 24 | £2.68 |
| 25 - 49 | £2.61 |
| 50 - 99 | £2.53 |
| 100 + | £2.48 |
**price indicative
- RS Stock No.:
- 909-7915
- Mfr. Part No.:
- 2-1440002-9
- Brand:
- TE Connectivity
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 24V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 16A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 240V | |
| Maximum Switching Voltage DC | 24V dc | |
| Length | 29.2mm | |
| Coil Resistance | 1100Ω | |
| Coil Power | 540mW | |
| Standards Met | CQC, CSA, UL | |
| Contact Material | Silver Alloy | |
| Life | 100000 (Electrical) Operations, 10000000 (Mechanical) Operations | |
| Height | 20.6mm | |
| Minimum Operating Temperature | -30°C | |
| Series | OZ | |
| Maximum Operating Temperature | +70°C | |
| Isolation Coil To Contact | 5kVrms | |
| Depth | 12.8mm | |
| Maximum Switching Power DC | 380 W | |
| Maximum Switching Power AC | 3.84 kVA | |
| Application | Home Appliances, Office Machines | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 24V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 16A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 240V | ||
Maximum Switching Voltage DC 24V dc | ||
Length 29.2mm | ||
Coil Resistance 1100Ω | ||
Coil Power 540mW | ||
Standards Met CQC, CSA, UL | ||
Contact Material Silver Alloy | ||
Life 100000 (Electrical) Operations, 10000000 (Mechanical) Operations | ||
Height 20.6mm | ||
Minimum Operating Temperature -30°C | ||
Series OZ | ||
Maximum Operating Temperature +70°C | ||
Isolation Coil To Contact 5kVrms | ||
Depth 12.8mm | ||
Maximum Switching Power DC 380 W | ||
Maximum Switching Power AC 3.84 kVA | ||
Application Home Appliances, Office Machines | ||
