Omron PCB Power Relay, 24V dc Coil, 30A Switching Current, DPST
- RS Stock No.:
- 789-6700
- Mfr. Part No.:
- G7L-2A-P-PV DC24
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£18.81
(exc. VAT)
£22.57
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 16 unit(s) shipping from 07 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £18.81 |
| 10 - 19 | £18.22 |
| 20 - 49 | £17.20 |
| 50 - 99 | £15.57 |
| 100 + | £14.75 |
*price indicative
- RS Stock No.:
- 789-6700
- Mfr. Part No.:
- G7L-2A-P-PV DC24
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Product Type | Power Relay | |
| Coil Voltage | 24V dc | |
| Contact Configuration | DPST | |
| Mount Type | PCB | |
| Series | G7L | |
| Terminal Type | Solder | |
| Switching Current | 30A | |
| Switching AC Voltage | 125V ac | |
| Switching Power | 1.9W | |
| Minimum Operating Temperature | -25°C | |
| Coil Resistance | 250Ω | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | CSA, UL | |
| Length | 52.5mm | |
| Coil Power | 1.9W | |
| Height | 47mm | |
| Width | 35.5mm | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 50mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Product Type Power Relay | ||
Coil Voltage 24V dc | ||
Contact Configuration DPST | ||
Mount Type PCB | ||
Series G7L | ||
Terminal Type Solder | ||
Switching Current 30A | ||
Switching AC Voltage 125V ac | ||
Switching Power 1.9W | ||
Minimum Operating Temperature -25°C | ||
Coil Resistance 250Ω | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals CSA, UL | ||
Length 52.5mm | ||
Coil Power 1.9W | ||
Height 47mm | ||
Width 35.5mm | ||
Contact Material Silver Alloy | ||
Contact Resistance 50mΩ | ||
PCB Mounting & Plug-in - Power Relays - G7L Series
Relay compatible with momentary voltage drops up to 50% of rated voltage
High capacity and high dielectric strength
Flame-resistance UL94V-0 insulation material
Choice of connection types available - quick-connect or PCB terminals
Suitable DIN rail/surface socket (Front connecting socket) and relay mounting clip (E-bracket) available separately for use with quick-connect types G7L-1A-T and G7L-2A-T (not to be used with G7L-1A-TUB and G7L-2A-TUB upper bracket mount types)
Approvals
UL; CSA; TÜV
