Siemens Power Relay, 115V ac Coil, 6A Switching Current, 4PDT
- RS Stock No.:
- 758-6895
- Mfr. Part No.:
- LZX:PT570615
- Brand:
- Siemens
Subtotal (1 unit)*
£9.47
(exc. VAT)
£11.36
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 14 unit(s) shipping from 13 April 2026
- Plus 2 unit(s) shipping from 13 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £9.47 |
*price indicative
- RS Stock No.:
- 758-6895
- Mfr. Part No.:
- LZX:PT570615
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Coil Voltage | 115V ac | |
| Product Type | Power Relay | |
| Contact Configuration | 4PDT | |
| Series | LZX | |
| Terminal Type | Screw | |
| Switching Current | 6A | |
| Switching DC Voltage | 24V dc | |
| Switching AC Voltage | 24V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Height | 28mm | |
| Width | 22.5mm | |
| Standards/Approvals | EAC, CE, UKCA, UL, VDE | |
| Length | 22.5mm | |
| Contact Material | Silver Nickel Alloy | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Coil Voltage 115V ac | ||
Product Type Power Relay | ||
Contact Configuration 4PDT | ||
Series LZX | ||
Terminal Type Screw | ||
Switching Current 6A | ||
Switching DC Voltage 24V dc | ||
Switching AC Voltage 24V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Height 28mm | ||
Width 22.5mm | ||
Standards/Approvals EAC, CE, UKCA, UL, VDE | ||
Length 22.5mm | ||
Contact Material Silver Nickel Alloy | ||
- COO (Country of Origin):
- AT
LZS Plug-in Relay
A range of plug-in coupling relays from Siemens available both as complete devices and as single modules for self assembly or spares. The complete LZS devices consist of a socket, plug-in relay, hold/reject clip, LED module and inscription label. All designs boast tried and tested screw or push-in, spring loaded terminals with hard gold-plated contacts for optimum interaction with electronic controls. The PT relay design does not feature a latching mechanism.
Tested to AC-15 and DC-13 switching capacity
Vibration proof connection
