Finder PCB Power Relay, 24V Coil, 50A Switching Current, DPDT
- RS Stock No.:
- 286-8588
- Mfr. Part No.:
- 66.22.9.024.4600
- Brand:
- Finder
Subtotal (1 unit)*
£19.06
(exc. VAT)
£22.87
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £19.06 |
*price indicative
- RS Stock No.:
- 286-8588
- Mfr. Part No.:
- 66.22.9.024.4600
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Product Type | Power Relay | |
| Coil Voltage | 24V | |
| Contact Configuration | DPDT | |
| Mount Type | PCB | |
| Series | 66 | |
| Switching Current | 50A | |
| Minimum Operating Temperature | -40°C | |
| Switching DC Voltage | 30V dc | |
| Switching AC Voltage | 440V ac | |
| Coil Resistance | 9.2kΩ | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | 8 mm creepage and clearance distances, EN 60335-1, D - T4 - T5 - T6, HazLoc Class I Div. 2 Group A, ATEX compliant (Ex ec nC) | |
| Contact Material | Silver Tin Oxide | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Product Type Power Relay | ||
Coil Voltage 24V | ||
Contact Configuration DPDT | ||
Mount Type PCB | ||
Series 66 | ||
Switching Current 50A | ||
Minimum Operating Temperature -40°C | ||
Switching DC Voltage 30V dc | ||
Switching AC Voltage 440V ac | ||
Coil Resistance 9.2kΩ | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals 8 mm creepage and clearance distances, EN 60335-1, D - T4 - T5 - T6, HazLoc Class I Div. 2 Group A, ATEX compliant (Ex ec nC) | ||
Contact Material Silver Tin Oxide | ||
- COO (Country of Origin):
- ES
The Finder Power Relays are designed with a focus on electrical safety, environmental considerations, and versatility in handling both AC and DC applications. They find use in various scenarios where reliable and safe switching of higher currents is necessary.
30 A rated contacts
PCB mount
