Omron PCB Power Relay, 24V dc Coil, 300A Switching Current, 1 NO
- RS Stock No.:
- 277-8730
- Mfr. Part No.:
- G9KA-1A-E-DC12
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£90.68
(exc. VAT)
£108.82
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 1 | £90.68 |
| 2 - 2 | £87.05 |
| 3 - 3 | £83.71 |
| 4 - 4 | £80.60 |
| 5 + | £77.72 |
*price indicative
- RS Stock No.:
- 277-8730
- Mfr. Part No.:
- G9KA-1A-E-DC12
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Product Type | Power Relay | |
| Coil Voltage | 24V dc | |
| Contact Configuration | 1 NO | |
| Mount Type | PCB | |
| Series | G9KA | |
| Switching Current | 300A | |
| Switching DC Voltage | 60V dc | |
| Switching AC Voltage | 1kV ac | |
| Minimum Operating Temperature | -40°C | |
| Coil Resistance | 115.2Ω | |
| Maximum Operating Temperature | 85°C | |
| Coil Power | 5W | |
| Length | 51mm | |
| Width | 51mm | |
| Standards/Approvals | CQC Certificated, EN/IEC, TÜV Certificated, UL Recognised | |
| Height | 54.5mm | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 0.2mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Product Type Power Relay | ||
Coil Voltage 24V dc | ||
Contact Configuration 1 NO | ||
Mount Type PCB | ||
Series G9KA | ||
Switching Current 300A | ||
Switching DC Voltage 60V dc | ||
Switching AC Voltage 1kV ac | ||
Minimum Operating Temperature -40°C | ||
Coil Resistance 115.2Ω | ||
Maximum Operating Temperature 85°C | ||
Coil Power 5W | ||
Length 51mm | ||
Width 51mm | ||
Standards/Approvals CQC Certificated, EN/IEC, TÜV Certificated, UL Recognised | ||
Height 54.5mm | ||
Contact Material Silver Alloy | ||
Contact Resistance 0.2mΩ | ||
The Omron High Power and Temperature Type Power Relay rises in board temperatures are suppressed by a low heat generation and high dissipation structure.
High impulse withstand voltage of 10 kV
Ambient temperature of 85 degree Celsius
