TE Connectivity PCB Mount Power Relay, 24V dc Coil, 6A Switching Current, SPDT
- RS Stock No.:
- 277-7215
- Distrelec Article No.:
- 301-67-806
- Mfr. Part No.:
- 3-1393236-0
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 unit)*
£6.79
(exc. VAT)
£8.15
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 522 unit(s) ready to ship
- Plus 999,999,477 unit(s) shipping from 11 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £6.79 |
| 10 + | £6.51 |
*price indicative
- RS Stock No.:
- 277-7215
- Distrelec Article No.:
- 301-67-806
- Mfr. Part No.:
- 3-1393236-0
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 24V dc | |
| Contact Configuration | SPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 6A | |
| Number of Poles | 1 | |
| Series | SCHRACK Slimline PCB Relay SNR | |
| Terminal Type | Through Hole | |
| Maximum Switching Voltage AC | 400V ac | |
| Length | 28mm | |
| Coil Resistance | 3.39 kΩ | |
| Coil Power | 170mW | |
| Maximum Operating Temperature | +85°C | |
| Contact Material | Silver Alloy | |
| Minimum Operating Temperature | -40°C | |
| Standards Met | RoHS Compliant | |
| Width | 5mm | |
| Application | PLC Application | |
| Dimensions | 29 x 12.7 x 15.7mm | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 24V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 6A | ||
Number of Poles 1 | ||
Series SCHRACK Slimline PCB Relay SNR | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 400V ac | ||
Length 28mm | ||
Coil Resistance 3.39 kΩ | ||
Coil Power 170mW | ||
Maximum Operating Temperature +85°C | ||
Contact Material Silver Alloy | ||
Minimum Operating Temperature -40°C | ||
Standards Met RoHS Compliant | ||
Width 5mm | ||
Application PLC Application | ||
Dimensions 29 x 12.7 x 15.7mm | ||
The TE Connectivity Schrack Power standard PCB relay used in Interface technology, PLC’s, timers, centralized and decentralized heating control.
Reinforced insulation
Cadmium free contacts
Strong coil pins for DIN rail socket
Cadmium free contacts
Strong coil pins for DIN rail socket
