- RS Stock No.:
- 271-1947
- Mfr. Part No.:
- MY4IN-GS-R DC24
- Brand:
- Omron
76 In stock - FREE next working day delivery available
Added
Price Each
£10.00
(exc. VAT)
£12.00
(inc. VAT)
Units | Per unit |
1 + | £10.00 |
- RS Stock No.:
- 271-1947
- Mfr. Part No.:
- MY4IN-GS-R DC24
- Brand:
- Omron
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
OMRON Power Relay, Single Coil, 2kV AC Coil-to-Contact Isolation - MY Series - MY4IN-GS-R DC24
Searching for a space-saving device that can manage multiple electrical loads at once? Reach for this miniature power relay from OMRON. It has a 4PDT configuration, so it's a practical choice when you need to control up to four individual circuits. As it's a latching relay type, this nifty piece of kit maintains its last contact position even after the input voltage has been cut. This means it needs less overall power than non-latching alternatives, helping you conserve resources.
Features & Benefits
• Compact dimensions of just 28 (H) x 21.5 (W) x 36mm (D) fit comfortably where space is limited
• Service life of 300,000 cycles, so it provides long-lasting performance
• Compatible with extreme conditions thanks to an operating temperature range of -55°C to +70°C
• Highly conductive silver contacts deliver a quality connection you can rely on
• Service life of 300,000 cycles, so it provides long-lasting performance
• Compatible with extreme conditions thanks to an operating temperature range of -55°C to +70°C
• Highly conductive silver contacts deliver a quality connection you can rely on
Applications
• Industrial motor control
• Commercial car washes
• HVAC systems
• Counting and sorting equipment
• Commercial car washes
• HVAC systems
• Counting and sorting equipment
How do I install this relay?
For convenience, this handy device plugs quickly and easily into a compatible socket.
What are the coil and switching voltages of this component?
For maximum user safety, the low 24V DC coil voltage produces a top switching voltage of 250V AC/DC, keeping workers and equipment isolated from high-energy systems.
Specifications
Attribute | Value |
---|---|
Coil Voltage | 24V dc |
Contact Configuration | 4PDT |
Mounting Type | Plug In |
Switching Current | 6A |
Number of Poles | 4 |
Latching | Yes |
Terminal Type | Plug In |
Maximum Switching Voltage AC | 250V |
Maximum Switching Voltage DC | 220V |
Maximum Switching Current AC | 6 A |
Maximum Switching Current DC | 6 A |
Length | 28mm |
Coil Resistance | 662 Ω |
Coil Power | 900mW |
Height | 36mm |
Isolation Coil To Contact | 2kV ac |
Maximum Operating Temperature | +70°C |
Series | MY |
Minimum Operating Temperature | -55°C |
Standards Met | CQC, CSA, IEC, UL |
Contact Material | Silver |
Depth | 36mm |
Life | 300000 cycles |
Maximum Switching Power AC | 3.6 VA |
Width | 21.5mm |
Number of Coils | Single |
Maximum Switching Power DC | 3600 mW |
Dimensions | 28 x 21.5 x 36mm |
Application | General Purpose, Industrial |
