Name: Omron Plug In Latching Power Relay, 24V ac Coil, 6A Switching Current, 4PDT
Brand: Omron
SKU: 271-1943
Price: 12.25 GBP
Availability: OutOfStock

OMRON Power Relay, 900mW Coil Power, 180Ω Coil Resistance - MY Series - MY4IN-GS-R AC24

Do you need a clever piece of kit to bring your industrial system to life? Use this 4PDT power relay from OMRON. It turns 24V AC devices like fans, pumps and motors on and off in a snap. Plug-in mounting makes installation a breeze. You can even speed up wiring by up to 60% by using a push-in socket (111-3063). As it carries out up to 2400 operations per hour, this is a reliable choice. With a high dielectric strength of 2kV, the component holds its own against sudden surges for up to one minute, protecting your equipment from damage and minimising downtime.

Features & Benefits

• 0.9W power consumption during operation for energy-efficiency
• Light 35g weight won't strain the socket
• Handy LED for easy monitoring and diagnostics
• Small dimensions of 36 (H) x 21.5 (W) x 28mm (L) take up minimal space in your system

Applications

• Water treatment plants
• Transportation industry
• Renewable energy installations
• Automotive production

What does 4PDT mean?

4PDT stands for four poles, double throw. It means the relay has four contacts that can switch four circuits on or off. You can use a 4PDT unit to change motor directions, control multiple devices or switch complex logic circuits.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Select all	Attribute	Value
	Brand	Omron
	Coil Voltage	24V ac
	Contact Configuration	4PDT
	Mounting Type	Plug In
	Switching Current	6A
	Number of Poles	4
	Latching	Yes
	Series	MY
	Terminal Type	Plug In
	Maximum Switching Voltage AC	250V
	Maximum Switching Voltage DC	220V
	Maximum Switching Current AC	6 A
	Maximum Switching Current DC	6 A
	Length	28mm
	Coil Resistance	180 Ω
	Coil Power	900mW
	Life	300000 cycles
	Maximum Operating Temperature	+70°C
	Height	36mm
	Isolation Coil To Contact	2kV ac
	Depth	36mm
	Minimum Operating Temperature	-55°C
	Contact Material	Silver
	Standards Met	CQC, CSA, IEC, UL
	Number of Coils	Single
	Maximum Switching Power AC	3.6 VA
	Maximum Switching Power DC	3600 mW
	Width	21.5mm
	Application	General Purpose, Industrial
	Dimensions	28 x 21.5 x 36mm

	Select all
	Brand Omron
	Coil Voltage 24V ac
	Contact Configuration 4PDT
	Mounting Type Plug In
	Switching Current 6A
	Number of Poles 4
	Latching Yes
	Series MY
	Terminal Type Plug In
	Maximum Switching Voltage AC 250V
	Maximum Switching Voltage DC 220V
	Maximum Switching Current AC 6 A
	Maximum Switching Current DC 6 A
	Length 28mm
	Coil Resistance 180 Ω
	Coil Power 900mW
	Life 300000 cycles
	Maximum Operating Temperature +70°C
	Height 36mm
	Isolation Coil To Contact 2kV ac
	Depth 36mm
	Minimum Operating Temperature -55°C
	Contact Material Silver
	Standards Met CQC, CSA, IEC, UL
	Number of Coils Single
	Maximum Switching Power AC 3.6 VA
	Maximum Switching Power DC 3600 mW
	Width 21.5mm
	Application General Purpose, Industrial
	Dimensions 28 x 21.5 x 36mm
