Omron Plug In Latching Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT

RS Stock No.:: 271-1941
Mfr. Part No.:: MY4IN-GS-R AC200/220
Brand:: Omron

Omron Plug In Latching Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT

Subtotal (1 unit)*

£10.21

(exc. VAT)

£12.25

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

76 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£10.21

*price indicative

RS Stock No.:: 271-1941
Mfr. Part No.:: MY4IN-GS-R AC200/220
Brand:: Omron

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Omron
	Coil Voltage	220 → 240V ac
	Contact Configuration	4PDT
	Mounting Type	Plug In
	Switching Current	6A
	Number of Poles	4
	Series	MY
	Latching	Yes
	Terminal Type	Plug In
	Maximum Switching Voltage AC	250V
	Maximum Switching Voltage DC	220V
	Maximum Switching Current AC	6 A
	Maximum Switching Current DC	6 A
	Length	28mm
	Coil Resistance	12.95 kΩ
	Coil Power	900mW
	Depth	36mm
	Standards Met	CQC, CSA, IEC, UL
	Minimum Operating Temperature	-55°C
	Life	300000 cycles
	Isolation Coil To Contact	2kV ac
	Contact Material	Silver
	Height	36mm
	Maximum Operating Temperature	+70°C
	Maximum Switching Power AC	3.6 VA
	Maximum Switching Power DC	3600 mW
	Number of Coils	Single
	Width	21.5mm
	Dimensions	28 x 21.5 x 36mm
	Application	General Purpose, Industrial

	Select all
	Brand Omron
	Coil Voltage 220 → 240V ac
	Contact Configuration 4PDT
	Mounting Type Plug In
	Switching Current 6A
	Number of Poles 4
	Series MY
	Latching Yes
	Terminal Type Plug In
	Maximum Switching Voltage AC 250V
	Maximum Switching Voltage DC 220V
	Maximum Switching Current AC 6 A
	Maximum Switching Current DC 6 A
	Length 28mm
	Coil Resistance 12.95 kΩ
	Coil Power 900mW
	Depth 36mm
	Standards Met CQC, CSA, IEC, UL
	Minimum Operating Temperature -55°C
	Life 300000 cycles
	Isolation Coil To Contact 2kV ac
	Contact Material Silver
	Height 36mm
	Maximum Operating Temperature +70°C
	Maximum Switching Power AC 3.6 VA
	Maximum Switching Power DC 3600 mW
	Number of Coils Single
	Width 21.5mm
	Dimensions 28 x 21.5 x 36mm
	Application General Purpose, Industrial

RoHS Status: Exempt

COO (Country of Origin):: CN

OMRON Power Relay, 240V AC Maximum Coil Voltage, 1000MΩ Insulation Resistance - MY Series - MY4IN-GS-R AC200/220

Ready to take charge of your equipment's electrical loads? Install this power relay from OMRON to your PCB. It controls the flow of electricity in your circuits so you can switch industrial devices on and off promptly. The silver nickel contacts reliably send power across in a flash while resisting corrosion, giving you a reliable connection you can bank on. Thanks to the latching lever, you can adjust this device between normal, momentary and locked states with ease. You'll find units like this used with motors, logical access controls and safety systems.

Features & Benefits

• Compact dimensions of 36 (H) x 21.5 (W) x 28mm (L) save space
• Consumes between 0.9 to 1.3W during operation, making it an energy-efficient option
• Wide operating temperature range of -55°C to +70°C for use in demanding applications
• LED indicator gives you speedy system checks

Applications

• Automotive industry
• Telecommunications networks
• Manufacturing plants

How do I mount this unit?

You can quickly install this unit by using a relay socket (196-6153), DIN rail socket (111-3063) or screw-in terminal (196-6147).

Is this power relay efficient?

Yes, as it handles up to 2400 operations per hour when using its rated load, it's suitable for fast-paced processes.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.
