    Omron Plug In Latching Power Relay, 12V ac Coil, 10A Switching Current, DPDT

    View all Power Relays

    Subtotal (1 unit)*

    £7.76

    (exc. VAT)

    £9.31

    (inc. VAT)

    Add to Basket
    Select or type quantity
    In Stock
    • 4 unit(s) ready to ship
    Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
    Units
    Per unit
    1 +£7.76

    *price indicative

    RS Stock No.:
    271-1919
    Mfr. Part No.:
    MY2IN-GS-R AC12
    Brand:
    Omron
    Find similar products by selecting one or more attributes.
    Select all

    Brand

    Omron

    Coil Voltage

    12V ac

    Contact Configuration

    DPDT

    Mounting Type

    Plug In

    Switching Current

    10A

    Number of Poles

    2

    Latching

    Yes

    Terminal Type

    Plug In

    Maximum Switching Voltage AC

    250V

    Maximum Switching Voltage DC

    220V

    Maximum Switching Current DC

    10 A

    Maximum Switching Current AC

    10 A

    Length

    28mm

    Coil Resistance

    46 Ω

    Coil Power

    900mW

    Depth

    36mm

    Life

    500000 cycles

    Height

    36mm

    Series

    MY

    Isolation Coil To Contact

    2kV ac

    Maximum Operating Temperature

    +70°C

    Minimum Operating Temperature

    -55°C

    Standards Met

    CQC, CSA, IEC, UL

    Contact Material

    Silver

    Maximum Switching Power AC

    10 VA

    Width

    21.5mm

    Maximum Switching Power DC

    10000 mW

    Number of Coils

    Single

    Dimensions

    28 x 21.5 x 36mm

    Application

    General Purpose, Industrial
