TE Connectivity Panel Mount Power Relay, 5V dc Coil, SPDT
- RS Stock No.:
- 267-4941
- Mfr. Part No.:
- 4-1415899-7
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 bag of 2 units)*
£5.56
(exc. VAT)
£6.68
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 36 unit(s) shipping from 27 October 2025
- Plus 999,999,962 unit(s) shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 - 2 | £2.78 | £5.56 |
| 4 - 8 | £2.605 | £5.21 |
| 10 - 18 | £2.38 | £4.76 |
| 20 - 28 | £2.085 | £4.17 |
| 30 + | £1.895 | £3.79 |
*price indicative
- RS Stock No.:
- 267-4941
- Mfr. Part No.:
- 4-1415899-7
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPDT | |
| Mounting Type | Panel Mount | |
| Number of Poles | 1 | |
| Series | SCHRACK Power PCB Relay RZ | |
| Latching | No | |
| Maximum Switching Voltage AC | 400V | |
| Length | 29mm | |
| Coil Resistance | 60 Ω | |
| Coil Power | 420mW | |
| Height | 15.7mm | |
| Minimum Operating Temperature | -55°C | |
| Contact Material | Silver Alloy | |
| Maximum Operating Temperature | +85°C | |
| Width | 12.7mm | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 5V dc | ||
Contact Configuration SPDT | ||
Mounting Type Panel Mount | ||
Number of Poles 1 | ||
Series SCHRACK Power PCB Relay RZ | ||
Latching No | ||
Maximum Switching Voltage AC 400V | ||
Length 29mm | ||
Coil Resistance 60 Ω | ||
Coil Power 420mW | ||
Height 15.7mm | ||
Minimum Operating Temperature -55°C | ||
Contact Material Silver Alloy | ||
Maximum Operating Temperature +85°C | ||
Width 12.7mm | ||
- COO (Country of Origin):
- AT
The TE Connectivity standard power relay has class F insulation coil with 30 A contact limiting making current and 16 A contact limiting breaking current.
Monostable
Printed circuit board mounting
Printed circuit board mounting
