Finder Panel Mount Latching Power Relay, 12V ac Coil, 10A Switching Current, SPST-NO
- RS Stock No.:
- 253-9976
- Distrelec Article No.:
- 136-70-176
- Mfr. Part No.:
- 26.01.8.012.0000
- Brand:
- Finder
Bulk discount available
Subtotal (1 unit)*
£13.97
(exc. VAT)
£16.76
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 825 unit(s) ready to ship
- Plus 58 unit(s) ready to ship from another location
- Plus 999,999,174 unit(s) shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £13.97 |
5 - 9 | £13.55 |
10 + | £13.02 |
*price indicative
- RS Stock No.:
- 253-9976
- Distrelec Article No.:
- 136-70-176
- Mfr. Part No.:
- 26.01.8.012.0000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Finder | |
Coil Voltage | 12V ac | |
Contact Configuration | SPST-NO | |
Mounting Type | Panel Mount | |
Switching Current | 10A | |
Number of Poles | 1 | |
Latching | Yes | |
Terminal Type | Screw | |
Maximum Switching Voltage AC | 400V ac | |
Length | 45mm | |
Coil Resistance | 17Ω | |
Coil Power | 4.5W | |
Height | 46.6mm | |
Depth | 22mm | |
Series | 26 | |
Contact Material | Silver Alloy | |
Isolation Coil To Contact | 4kV | |
Life | 100000 (Electrical) cycles, 300000 (DC/AC Mechanical) cycles | |
Minimum Operating Temperature | -40°C | |
Standards Met | CE, EAC | |
Maximum Operating Temperature | +40°C | |
Maximum Switching Power AC | 2.5 kVA | |
Select all | ||
---|---|---|
Brand Finder | ||
Coil Voltage 12V ac | ||
Contact Configuration SPST-NO | ||
Mounting Type Panel Mount | ||
Switching Current 10A | ||
Number of Poles 1 | ||
Latching Yes | ||
Terminal Type Screw | ||
Maximum Switching Voltage AC 400V ac | ||
Length 45mm | ||
Coil Resistance 17Ω | ||
Coil Power 4.5W | ||
Height 46.6mm | ||
Depth 22mm | ||
Series 26 | ||
Contact Material Silver Alloy | ||
Isolation Coil To Contact 4kV | ||
Life 100000 (Electrical) cycles, 300000 (DC/AC Mechanical) cycles | ||
Minimum Operating Temperature -40°C | ||
Standards Met CE, EAC | ||
Maximum Operating Temperature +40°C | ||
Maximum Switching Power AC 2.5 kVA | ||
- COO (Country of Origin):
- IT

Finder Series 26 Power Relay, SPST-NO Contact Configuration, 12V AC Coil Voltage - 26.01.8.012.0000
This power relay is designed for efficient control in various automation tasks. It features a coil voltage of 12V AC and is an SPST-NO relay, presented in a compact panel mount design with dimensions of 45mm x 22mm x 46.6mm. Its robust construction makes it suitable for environments that require consistent performance across different load conditions.
Features & Benefits
• Seamless panel mounting for user convenience
• Utilises a latching mechanism for improved energy efficiency
• Supports a maximum switching voltage of 400V AC
• Utilises AgNi contact material for durability
• Endures up to 100,000 electrical life cycles
• Equipped with screw terminal connections for easy wiring
• Utilises a latching mechanism for improved energy efficiency
• Supports a maximum switching voltage of 400V AC
• Utilises AgNi contact material for durability
• Endures up to 100,000 electrical life cycles
• Equipped with screw terminal connections for easy wiring
Applications
• Controls corridor lighting in hotels and offices
• Manages lighting in bedrooms and living rooms
• Compatible with various electrical devices in hospitals
• Used in automation systems requiring dependable control
• Manages lighting in bedrooms and living rooms
• Compatible with various electrical devices in hospitals
• Used in automation systems requiring dependable control
Can it operate under extreme temperatures?
Yes, it functions within a range of -40°C to +40°C.
Will it provide isolation between coil and contacts?
Yes, it features an isolation rating of 4kV.
Is it suitable for single-phase applications?
Yes, it is designed as a single-phase switch (1 NO).
Can it handle significant maximum switching power?
Yes, it can manage up to 2.5 kVA switching power.
