Finder PCB Relay, 120V ac Coil, 30A Switching Current, 2 CO
- RS Stock No.:
- 248-2648
- Mfr. Part No.:
- 662281200000
- Brand:
- Finder
Subtotal (1 pack of 10 units)*
£168.98
(exc. VAT)
£202.78
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 05 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 + | £16.898 | £168.98 |
*price indicative
- RS Stock No.:
- 248-2648
- Mfr. Part No.:
- 662281200000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 120V ac | |
| Product Type | Relay | |
| Contact Configuration | 2 CO | |
| Mount Type | PCB | |
| Series | 66 | |
| Terminal Type | Screw | |
| Switching Current | 30A | |
| Switching AC Voltage | 250V ac | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Coil Resistance | 1.1kΩ | |
| Standards/Approvals | CSA, EAC | |
| Coil Power | 3.6VA | |
| Length | 51.5mm | |
| Height | 35mm | |
| Width | 33.5mm | |
| Contact Material | Silver Alloy Gold Plated | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 120V ac | ||
Product Type Relay | ||
Contact Configuration 2 CO | ||
Mount Type PCB | ||
Series 66 | ||
Terminal Type Screw | ||
Switching Current 30A | ||
Switching AC Voltage 250V ac | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Coil Resistance 1.1kΩ | ||
Standards/Approvals CSA, EAC | ||
Coil Power 3.6VA | ||
Length 51.5mm | ||
Height 35mm | ||
Width 33.5mm | ||
Contact Material Silver Alloy Gold Plated | ||
The Finder's 66 series 30A power relay with 2 pole changeover contact, LED, mechanical indicator and test button options. This power relays used in applications like road or tunnel lighting, industrial furnaces, burners, boilers, ovens, circuit breakers, control and management of electric power etc.
PCB mount - bifurcated terminals
2 pole changeover (DPDT)
Cadmium free contact material options
Have both AC and DC coils
