Panasonic PCB Non-Latching Relay, 1.5V dc Coil, 266.7mA Switching Current, SPDT
- RS Stock No.:
- 247-4309
- Mfr. Part No.:
- DS1E-M-DC1.5V
- Brand:
- Panasonic
Bulk discount available
View bulk pricing optionsSubtotal (1 tube of 50 units)*
£367.50
(exc. VAT)
£441.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 16 April 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 50 - 50 | £7.35 | £367.50 |
| 100 - 200 | £7.085 | £354.25 |
| 250 - 450 | £6.946 | £347.30 |
| 500 + | £6.681 | £334.05 |
*price indicative
- RS Stock No.:
- 247-4309
- Mfr. Part No.:
- DS1E-M-DC1.5V
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Coil Voltage | 1.5V dc | |
| Product Type | Non-Latching Relay | |
| Contact Configuration | SPDT | |
| Mount Type | PCB | |
| Series | DS RELAYS | |
| Terminal Type | Solder | |
| Switching Current | 266.7mA | |
| Switching AC Voltage | 250V ac | |
| Minimum Operating Temperature | -40°C | |
| Switching Power | 125VA | |
| Maximum Operating Temperature | 70°C | |
| Coil Resistance | 11.5kΩ | |
| Coil Power | 200mW | |
| Width | 7mm | |
| Standards/Approvals | CSA (Certified), UL (Recognised) | |
| Height | 12mm | |
| Length | 22mm | |
| Contact Material | Silver Alloy Gold Plated | |
| Contact Resistance | 50mΩ | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Coil Voltage 1.5V dc | ||
Product Type Non-Latching Relay | ||
Contact Configuration SPDT | ||
Mount Type PCB | ||
Series DS RELAYS | ||
Terminal Type Solder | ||
Switching Current 266.7mA | ||
Switching AC Voltage 250V ac | ||
Minimum Operating Temperature -40°C | ||
Switching Power 125VA | ||
Maximum Operating Temperature 70°C | ||
Coil Resistance 11.5kΩ | ||
Coil Power 200mW | ||
Width 7mm | ||
Standards/Approvals CSA (Certified), UL (Recognised) | ||
Height 12mm | ||
Length 22mm | ||
Contact Material Silver Alloy Gold Plated | ||
Contact Resistance 50mΩ | ||
- COO (Country of Origin):
- JP
The Panasonic makes DS series of signal relays, this relay has 1 form C contact arrangement. The rated voltage for this relay is 1.5 Vdc. This relay operates on single side stable function. It is used in applications like telecommunications measurement equipment, OA equipment information related equipment and industrial machines.
200 mW rated operating power
High sensitivity versions available
