Omron PCB Non-Latching Relay, 5 V dc Coil, 12 A Switching Current, SPST

View all Power Relays
Bulk discount available

Subtotal (1 tube of 100 units)*

£489.70

(exc. VAT)

£587.60

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later
Units
Per unit
Per Tube*
100 - 400£4.897£489.70
500 - 900£4.795£479.50
1000 +£4.692£469.20

*price indicative

RS Stock No.:
232-6224
Mfr. Part No.:
G2RL-1A-E-PW1 DC5
Brand:
Omron
Find similar products by selecting one or more attributes.
Select all

Brand

Omron

Coil Voltage

5 V dc

Product Type

Non-Latching Relay

Contact Configuration

SPST

Mount Type

PCB

Series

G2RL

Terminal Type

Solder

Switching Current

12 A

Switching AC Voltage

440 V ac

Switching DC Voltage

300 V dc

Minimum Operating Temperature

-40°C

Coil Resistance

62.5Ω

Maximum Operating Temperature

85°C

Width

12.7 mm

Length

29mm

Standards/Approvals

VDE, RoHS, IEC/EN 60079-15

Coil Power

400mW

Height

15.7mm

Contact Material

Silver Alloy

Contact Resistance

100mΩ

COO (Country of Origin):
MY
The Omron G2RL series low profile power relay with 15.7 mm height, ideal for incorporation in miniature equipment's. It has a 1 pole and use for home appliances and industrial machinery.

A wide variety of single pole high-capacity (16 A)

IEC/EN 60335-1 conformed. (-HA Model)

Satisfies ambient operating temperature requirement of 85°C and 105°C (-CV Model)

Clearance and creepage distance: 8 mm / 8 mm min

Reduced power consumption with volt
