Omron PCB Mount Non-Latching Relay, 5V dc Coil, 12A Switching Current, SPDT
- RS Stock No.:
- 232-6238
- Mfr. Part No.:
- G2RL-1-E-PW1 DC5
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£4.34
(exc. VAT)
£5.21
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 21 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £4.34 |
| 10 - 49 | £4.24 |
| 50 + | £4.14 |
*price indicative
- RS Stock No.:
- 232-6238
- Mfr. Part No.:
- G2RL-1-E-PW1 DC5
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 12A | |
| Number of Poles | 1 | |
| Series | G2RL | |
| Coil Resistance | 62.5 Ω | |
| Coil Power | 400mW | |
| Isolation Coil To Contact | 10kV | |
| Number of Coils | Single | |
Select all | ||
|---|---|---|
Brand Omron | ||
Coil Voltage 5V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 12A | ||
Number of Poles 1 | ||
Series G2RL | ||
Coil Resistance 62.5 Ω | ||
Coil Power 400mW | ||
Isolation Coil To Contact 10kV | ||
Number of Coils Single | ||
- COO (Country of Origin):
- MY
The Omron G2RL series low profile power relay with 15.7 mm height, ideal for incorporation in miniature equipment's. It has a 1 pole and use for home appliances and industrial machinery.
A wide variety of single pole high-capacity (16 A)
IEC/EN 60335-1 conformed. (-HA Model)
Satisfies ambient operating temperature requirement of 85°C and 105°C (-CV Model)
Clearance and creepage distance: 8 mm / 8 mm min
Reduced power consumption with volt
IEC/EN 60335-1 conformed. (-HA Model)
Satisfies ambient operating temperature requirement of 85°C and 105°C (-CV Model)
Clearance and creepage distance: 8 mm / 8 mm min
Reduced power consumption with volt
