Fujitsu PCB Power Relay, 5V Coil, 5A Switching Current, 1 NO
- RS Stock No.:
- 195-8150
- Mfr. Part No.:
- JV-5-KT
- Brand:
- Fujitsu
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 195-8150
- Mfr. Part No.:
- JV-5-KT
- Brand:
- Fujitsu
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Fujitsu | |
| Product Type | Power Relay | |
| Coil Voltage | 5V | |
| Contact Configuration | 1 NO | |
| Mount Type | PCB | |
| Series | JV | |
| Terminal Type | PCB Pin | |
| Switching Current | 5A | |
| Minimum Operating Temperature | -40°C | |
| Switching Power | 150W | |
| Switching DC Voltage | 150V dc | |
| Switching AC Voltage | 150V ac | |
| Coil Resistance | 83.3Ω | |
| Maximum Operating Temperature | 70°C | |
| Length | 17.8mm | |
| Width | 10.3mm | |
| Height | 12.8mm | |
| Standards/Approvals | RoHS | |
| Coil Power | 300mW | |
| Contact Material | Silver Alloy | |
| Select all | ||
|---|---|---|
Brand Fujitsu | ||
Product Type Power Relay | ||
Coil Voltage 5V | ||
Contact Configuration 1 NO | ||
Mount Type PCB | ||
Series JV | ||
Terminal Type PCB Pin | ||
Switching Current 5A | ||
Minimum Operating Temperature -40°C | ||
Switching Power 150W | ||
Switching DC Voltage 150V dc | ||
Switching AC Voltage 150V ac | ||
Coil Resistance 83.3Ω | ||
Maximum Operating Temperature 70°C | ||
Length 17.8mm | ||
Width 10.3mm | ||
Height 12.8mm | ||
Standards/Approvals RoHS | ||
Coil Power 300mW | ||
Contact Material Silver Alloy | ||
- COO (Country of Origin):
- CN
Low profile and space saving
Height: 12.5 mm
Mounting space: 175 mm2
High sensitivity in small package
Operating power: 0.112 to 0.13 W
Nominal power: 0.2 to 0.3 W
High insulation with reinforced insulation system (between coil and contacts)Insulation distance: 8 mm
Dielectric strength: 5,000 VAC
Surge strength: 10,000 V
Plastic materials
Plastic sealed type
