Fujitsu PCB Mount Power Relay, 9V dc Coil, 5A Switching Current, SPST
- RS Stock No.:
- 195-8159
- Mfr. Part No.:
- JV-9S-KT
- Brand:
- Fujitsu
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 195-8159
- Mfr. Part No.:
- JV-9S-KT
- Brand:
- Fujitsu
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Fujitsu | |
Coil Voltage | 9V dc | |
Contact Configuration | SPST | |
Mounting Type | PCB Mount | |
Switching Current | 5A | |
Number of Poles | 1 | |
Latching | No | |
Terminal Type | PCB Pin | |
Maximum Switching Voltage AC | 250V ac | |
Maximum Switching Voltage DC | 150V dc | |
Maximum Switching Current AC | 5 A | |
Maximum Switching Current DC | 5 A | |
Length | 17.8mm | |
Coil Resistance | 270Ω | |
Coil Power | 300mW | |
Height | 12.8mm | |
Series | JV | |
Isolation Coil To Contact | 10000 (Surge)V | |
Depth | 10.3mm | |
Maximum Switching Power DC | 150 W | |
Maximum Switching Power AC | 1.25 kVA | |
Select all | ||
---|---|---|
Brand Fujitsu | ||
Coil Voltage 9V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 5A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 250V ac | ||
Maximum Switching Voltage DC 150V dc | ||
Maximum Switching Current AC 5 A | ||
Maximum Switching Current DC 5 A | ||
Length 17.8mm | ||
Coil Resistance 270Ω | ||
Coil Power 300mW | ||
Height 12.8mm | ||
Series JV | ||
Isolation Coil To Contact 10000 (Surge)V | ||
Depth 10.3mm | ||
Maximum Switching Power DC 150 W | ||
Maximum Switching Power AC 1.25 kVA | ||
