Fujitsu PCB Mount Power Relay, 12V dc Coil, 5A Switching Current, SPST
- RS Stock No.:
- 195-8137
- Mfr. Part No.:
- JV-12-KT
- Brand:
- Fujitsu
Bulk discount available
Subtotal (1 unit)**
£1.99
(exc. VAT)
£2.39
(inc. VAT)
61 In stock - FREE next working day delivery available*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over £50.00
Check stock levels
Units | Per unit |
|---|---|
| 1 - 4 | £1.99 |
| 5 - 9 | £1.78 |
| 10 + | £1.69 |
**price indicative
- RS Stock No.:
- 195-8137
- Mfr. Part No.:
- JV-12-KT
- Brand:
- Fujitsu
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Fujitsu | |
| Coil Voltage | 12V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 5A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 250V ac | |
| Maximum Switching Voltage DC | 150V dc | |
| Maximum Switching Current DC | 5 A | |
| Maximum Switching Current AC | 5 A | |
| Length | 17.8mm | |
| Coil Resistance | 480Ω | |
| Coil Power | 300mW | |
| Isolation Coil To Contact | 10000 (Surge)V | |
| Series | JV | |
| Height | 12.8mm | |
| Depth | 10.3mm | |
| Maximum Switching Power DC | 150 W | |
| Maximum Switching Power AC | 1.25 kVA | |
Select all | ||
|---|---|---|
Brand Fujitsu | ||
Coil Voltage 12V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 5A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 250V ac | ||
Maximum Switching Voltage DC 150V dc | ||
Maximum Switching Current DC 5 A | ||
Maximum Switching Current AC 5 A | ||
Length 17.8mm | ||
Coil Resistance 480Ω | ||
Coil Power 300mW | ||
Isolation Coil To Contact 10000 (Surge)V | ||
Series JV | ||
Height 12.8mm | ||
Depth 10.3mm | ||
Maximum Switching Power DC 150 W | ||
Maximum Switching Power AC 1.25 kVA | ||
