Hongfa Europe GMBH PCB Power Relay, 24V dc Coil, 10A Switching Current, DPDT
- RS Stock No.:
- 176-2972
- Mfr. Part No.:
- HF115FK/24-2Z4T(610)
- Brand:
- Hongfa Europe GMBH
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 176-2972
- Mfr. Part No.:
- HF115FK/24-2Z4T(610)
- Brand:
- Hongfa Europe GMBH
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hongfa Europe GMBH | |
| Coil Voltage | 24V dc | |
| Product Type | Power Relay | |
| Contact Configuration | DPDT | |
| Mount Type | PCB | |
| Series | HF115FK | |
| Terminal Type | PCB Pin | |
| Switching Current | 10A | |
| Switching Power | 2kVA | |
| Switching AC Voltage | 400V ac | |
| Minimum Operating Temperature | -40°C | |
| Coil Resistance | 1.4kΩ | |
| Maximum Operating Temperature | 85°C | |
| Height | 15.7mm | |
| Length | 29mm | |
| Standards/Approvals | RoHS | |
| Width | 12.7mm | |
| Coil Power | 400mW | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 24V dc | ||
Product Type Power Relay | ||
Contact Configuration DPDT | ||
Mount Type PCB | ||
Series HF115FK | ||
Terminal Type PCB Pin | ||
Switching Current 10A | ||
Switching Power 2kVA | ||
Switching AC Voltage 400V ac | ||
Minimum Operating Temperature -40°C | ||
Coil Resistance 1.4kΩ | ||
Maximum Operating Temperature 85°C | ||
Height 15.7mm | ||
Length 29mm | ||
Standards/Approvals RoHS | ||
Width 12.7mm | ||
Coil Power 400mW | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
Hongfa DPDT Non-Latching Relay PCB Mount
The Hongfa DPDT non-latching electromagnetic 2-pole PCB mount relay is a miniature form power relay of intermediate category. It is actuated with the help of a 24VDC coil and up to 10A DC/AC current through the coil for the relay to switch positions. This relay has silver alloy contacts.
Features and Benefits
• High power switching up to 2KV in case of AC
• Service temperature range between -40°C and 85°C
• Isolation voltage between coil and contact is 5KVAC
• Flux proofed type
• Environmental friendly product
Applications
• Used as a control device
• Automotive industry
