Hongfa Europe GMBH PCB Power Relay, 5V dc Coil, 20A, SPDT

View all Signal Relays

Subtotal (1 unit)*

£3.75

(exc. VAT)

£4.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 5 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£3.75

*price indicative

RS Stock No.:
176-2969
Mfr. Part No.:
HF115F-L/5-Z3L2TF(610)
Brand:
Hongfa Europe GMBH
Find similar products by selecting one or more attributes.
Select all

Brand

Hongfa Europe GMBH

Coil Voltage

5V dc

Product Type

Power Relay

Contact Configuration

SPDT

Mount Type

PCB

Switching Current

20A

Switching AC Voltage

440V ac

Switching DC Voltage

300V dc

Series

HF115F-L

Switching Power

4000VA

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

Height

15.7mm

Length

29mm

Terminal Type

PCB Terminal

Width

12.7mm

Standards/Approvals

RoHS

Contact Resistance

100mΩ

Contact Material

Silver Alloy

Coil Resistance

62Ω

Coil Power

600mW

COO (Country of Origin):
CN

Hongfa Europe GMBH SPDT Latching Relay


The Hongfa SPDT latching PCB mount relay has a low mounting height of 15.7mm. It is actuated with the help of a 5VDC Coil and up to 20A DC/AC current through the Coil for the relay to switch position. It is a double Coil latching relay with silver alloy contact.

Features and Benefits


• Provides high power switching up to 900W in case of DC

• Wide operating temperature range of -40°C and 85°C

• Isolation between Coil and contact is 5kV

• Durability up to 2 x 106 cycles

• Environmental friendly product

• Plastic sealed and flux proofed types available

Applications


• Automotive engines and household appliances

• Industrial machinery and medical equipment

• Telecommunication equipment
