Hongfa Europe GMBH PCB Mount Power Relay, 5V dc Coil, 10A Switching Current, SPST
- RS Stock No.:
- 176-2640
- Mfr. Part No.:
- HF33F/005-HSL3F
- Brand:
- Hongfa Europe GMBH
Subtotal (1 box of 100 units)*
£80.20
(exc. VAT)
£96.20
(inc. VAT)
FREE delivery for orders over £50.00
- 300 unit(s) ready to ship
- Plus 1,000 unit(s) shipping from 18 December 2025
- Plus 1,000 unit(s) shipping from 12 February 2026
Units | Per unit | Per Box* |
|---|---|---|
| 100 + | £0.802 | £80.20 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Pack of 5)
£1.032
(exc. VAT)
£1.238
(inc. VAT)
- RS Stock No.:
- 176-2640
- Mfr. Part No.:
- HF33F/005-HSL3F
- Brand:
- Hongfa Europe GMBH
Select all | Attribute | Value |
|---|---|---|
| Brand | Hongfa Europe GMBH | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 10A | |
| Number of Poles | 1 | |
| Series | HF33F | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 250V | |
| Maximum Switching Voltage DC | 30V dc | |
| Maximum Switching Current AC | 10 A | |
| Maximum Switching Current DC | 10 A | |
| Length | 20.5mm | |
| Coil Resistance | 55Ω | |
| Coil Power | 200mW | |
| Life | 5 x 10^6 cycles | |
| Height | 15.3mm | |
| Contact Material | Silver Alloy | |
| Depth | 10.2mm | |
| Standards Met | CQC File No:CQC09002028694, cULus File No:E134517, VDE File No:125661 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +70°C | |
| Isolation Coil To Contact | 4kV ac | |
| Maximum Switching Power DC | 150 W | |
| Maximum Switching Power AC | 1.25 kVA | |
| Dimensions | 20.5 x 10.2 x 15.3mm | |
Select all | ||
|---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 10A | ||
Number of Poles 1 | ||
Series HF33F | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 250V | ||
Maximum Switching Voltage DC 30V dc | ||
Maximum Switching Current AC 10 A | ||
Maximum Switching Current DC 10 A | ||
Length 20.5mm | ||
Coil Resistance 55Ω | ||
Coil Power 200mW | ||
Life 5 x 10^6 cycles | ||
Height 15.3mm | ||
Contact Material Silver Alloy | ||
Depth 10.2mm | ||
Standards Met CQC File No:CQC09002028694, cULus File No:E134517, VDE File No:125661 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +70°C | ||
Isolation Coil To Contact 4kV ac | ||
Maximum Switching Power DC 150 W | ||
Maximum Switching Power AC 1.25 kVA | ||
Dimensions 20.5 x 10.2 x 15.3mm | ||
- COO (Country of Origin):
- CN
Hongfa SPNO Non-Latching Relay
Features and Benefits
• Service temperature range of -40°C and 70°C
• Durability up to 5 x 106 cycles
• Environmental friendly product
• Plastic sealed and fluxed proofed types
Applications
• Household appliances
• Industrial machinery
• Medical equipment
• Telecommunication equipment
