Panasonic PCB Mount Latching Power Relay, 5V dc Coil, 8A Switching Current, SPST
- RS Stock No.:
- 173-8207
- Mfr. Part No.:
- DE1AL25
- Brand:
- Panasonic
Subtotal (1 tube of 20 units)*
£94.10
(exc. VAT)
£112.92
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 80 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 20 + | £4.705 | £94.10 |
*price indicative
- RS Stock No.:
- 173-8207
- Mfr. Part No.:
- DE1AL25
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 8A | |
| Latching | Yes | |
| Terminal Type | Through Hole | |
| Maximum Switching Voltage AC | 440V ac | |
| Maximum Switching Voltage DC | 230V dc | |
| Length | 25mm | |
| Coil Resistance | 125Ω | |
| Maximum Operating Temperature | +70°C | |
| Height | 12.5mm | |
| Contact Material | Silver Alloy | |
| Depth | 12.5mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Switching Power DC | 300 W | |
| Maximum Switching Power AC | 2.5 kVA | |
| Dimensions | 25 x 12.5 x 12.5mm | |
| Application | Power | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 8A | ||
Latching Yes | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 440V ac | ||
Maximum Switching Voltage DC 230V dc | ||
Length 25mm | ||
Coil Resistance 125Ω | ||
Maximum Operating Temperature +70°C | ||
Height 12.5mm | ||
Contact Material Silver Alloy | ||
Depth 12.5mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Switching Power DC 300 W | ||
Maximum Switching Power AC 2.5 kVA | ||
Dimensions 25 x 12.5 x 12.5mm | ||
Application Power | ||
- COO (Country of Origin):
- JP
DE series bistable relay
Bistable 2-coil compact relays for direct control of strip lights and air conditioning.
Galvanic separation between inputs and outputs with 8 mm leakage path and an aerial distance between the coil and the contacts that guarantees safe cut-off.
Enhanced safety thanks to linked contacts that avoid malfunctions.
Galvanic separation between inputs and outputs with 8 mm leakage path and an aerial distance between the coil and the contacts that guarantees safe cut-off.
Enhanced safety thanks to linked contacts that avoid malfunctions.
