Panasonic PCB Mount Power Relay, 24V dc Coil, 10A Switching Current, SPST
- RS Stock No.:
- 134-7938
- Mfr. Part No.:
- ALQ3F24
- Brand:
- Panasonic
Subtotal (1 unit)*
£1.51
(exc. VAT)
£1.81
(inc. VAT)
FREE delivery for orders over £50.00
- 256 unit(s) ready to ship
- Plus 999,999,743 unit(s) shipping from 04 March 2026
Units | Per unit |
|---|---|
| 1 + | £1.51 |
*price indicative
- RS Stock No.:
- 134-7938
- Mfr. Part No.:
- ALQ3F24
- Brand:
- Panasonic
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Coil Voltage | 24V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 10A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 250V | |
| Maximum Switching Voltage DC | 30V dc | |
| Length | 20mm | |
| Coil Resistance | 2880Ω | |
| Coil Power | 200mW | |
| Minimum Operating Temperature | -40°C | |
| Height | 15.6mm | |
| Maximum Operating Temperature | +85°C | |
| Isolation Coil To Contact | 4kVrms | |
| Life | Minimum of 10000000 (Mechanical) operations | |
| Contact Material | Silver Alloy | |
| Depth | 10mm | |
| Standards Met | CQC, CSA, cUL, cULus, UL, VDE | |
| Maximum Switching Power DC | 150 W | |
| Maximum Switching Power AC | 1.25 kVA | |
| Application | Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Coil Voltage 24V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 10A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 250V | ||
Maximum Switching Voltage DC 30V dc | ||
Length 20mm | ||
Coil Resistance 2880Ω | ||
Coil Power 200mW | ||
Minimum Operating Temperature -40°C | ||
Height 15.6mm | ||
Maximum Operating Temperature +85°C | ||
Isolation Coil To Contact 4kVrms | ||
Life Minimum of 10000000 (Mechanical) operations | ||
Contact Material Silver Alloy | ||
Depth 10mm | ||
Standards Met CQC, CSA, cUL, cULus, UL, VDE | ||
Maximum Switching Power DC 150 W | ||
Maximum Switching Power AC 1.25 kVA | ||
Application Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine | ||
