TE Connectivity PCB Mount Power Relay, 5V dc Coil, 5A Switching Current, DPDT
- RS Stock No.:
- 515-533
- Distrelec Article No.:
- 301-19-739
- Mfr. Part No.:
- 9-1462038-9 IM03DGR
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 unit)*
£2.89
(exc. VAT)
£3.47
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 390 unit(s) shipping from 24 November 2025
- Plus 119 unit(s) shipping from 24 November 2025
- Plus 10,320 unit(s) shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £2.89 |
| 10 - 24 | £2.75 |
| 25 - 99 | £2.61 |
| 100 - 249 | £2.45 |
| 250 + | £2.18 |
*price indicative
- RS Stock No.:
- 515-533
- Distrelec Article No.:
- 301-19-739
- Mfr. Part No.:
- 9-1462038-9 IM03DGR
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Coil Voltage | 5V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 5A | |
| Number of Poles | 2 | |
| Latching | No | |
| Series | IM | |
| Terminal Type | Surface Mount | |
| Length | 10mm | |
| Coil Resistance | 178Ω | |
| Coil Power | 140mW | |
| Contact Material | Gold Plated | |
| Maximum Operating Temperature | +85°C | |
| Depth | 7.5mm | |
| Height | 5.7mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Switching Power DC | 60 W | |
| Maximum Switching Power AC | 62.5VA | |
| Application | Signal | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Coil Voltage 5V dc | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Switching Current 5A | ||
Number of Poles 2 | ||
Latching No | ||
Series IM | ||
Terminal Type Surface Mount | ||
Length 10mm | ||
Coil Resistance 178Ω | ||
Coil Power 140mW | ||
Contact Material Gold Plated | ||
Maximum Operating Temperature +85°C | ||
Depth 7.5mm | ||
Height 5.7mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Switching Power DC 60 W | ||
Maximum Switching Power AC 62.5VA | ||
Application Signal | ||
Telecom/Signal Relay IM Series
Slimline and low profile - 10x6x5.65 mm
Gull wing SMT legs
Bifurcated contacts, gold plated
Hermetically sealed (RT V), IP67
High mechanical shock resistance up to 300G functional, 500G survival
Insulation resistance at 500Vdc >109Ω
High surge capability - meets Telcordia TR-NWT-001089 (2 / 10 μs) & EC 60950 (10 / 700 μs)
Gull wing SMT legs
Bifurcated contacts, gold plated
Hermetically sealed (RT V), IP67
High mechanical shock resistance up to 300G functional, 500G survival
Insulation resistance at 500Vdc >109Ω
High surge capability - meets Telcordia TR-NWT-001089 (2 / 10 μs) & EC 60950 (10 / 700 μs)
Approvals
UL
