Schaffner, FN2020 60A 250 V ac 0 → 400Hz, Chassis Mount Power Line Filter, Stud, Single Phase
- RS Stock No.:
- 881-7332
- Mfr. Part No.:
- FN2020-60-24
- Brand:
- Schaffner
Available to back order for despatch when stock is available
Added
Price Each
£108.08
(exc. VAT)
£129.70
(inc. VAT)
| Units | Per unit |
| 1 + | £108.08 |
- RS Stock No.:
- 881-7332
- Mfr. Part No.:
- FN2020-60-24
- Brand:
- Schaffner
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
FN2020 Series
FN2020 filters are designed for easy and fast chassis mounting and are also avaialble as B versions, the Medical option and A version the Safety option. All FN2020 filters provide a general purpose attenuation performance, based on chokes with high saturation resistance and excellent thermal behaviour.
Higher phase to neutral capacitance for better differential mode performance
Connection by 0.25in Faston terminals
Connection by 0.25in Faston terminals
Approvals
UL recognised component, CSA certified, VDE
Specifications
Attribute | Value |
|---|---|
| Maximum Current Rating | 60A |
| Maximum Voltage Rating | 250 V ac |
| Mounting Type | Chassis Mount |
| Termination Style | Stud |
| Number of Phases | 1 |
| Series | FN2020 |
| Operating Frequency | 0 → 400Hz |
| Length | 105mm |
| Depth | 99.5mm |
| Height | 57.6mm |
| Dimensions | 105 x 99.5 x 57.6mm |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +100°C |
