RS PRO Tri-rated 1 mm 1 Core Electrical Cable, White Polyvinyl Chloride PVC, 305m

View all Power Cable

Subtotal (1 reel of 305 metres)*

£99.85

(exc. VAT)

£119.82

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 5 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s)
Per Reel
Per Metre*
1 +£99.85£0.327

*price indicative

RS Stock No.:
255-7263
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Cross Sectional Area

1 mm

Number of Cores

1

Sheath Colour

White

Length

305m

Cable Type

Tri-rated

Current Rating

17 A

CPR Certification

Eca

Sheath Material

Polyvinyl Chloride PVC

Voltage Rating

600-1000 V

RoHS Status: Exempt

COO (Country of Origin):
GB

RS PRO Tri-rated Cable


Our RS PRO tri-rated cable has been designed to be used within electrical equipment, most commonly for wiring items that include power switchgear. The cable is also great for internal connections within rectifier equipment, motor starters, and controllers. Our RS PRO tri-rated cable range features highly durable wires that are made with flexible copper and are encased with a HR PVC (heat resistant polyvinyl chloride) insulation.

The high maximum operating temperature of 105°C allows them to be used with a wide variety of applications such as electrical cabinets. RS PRO tri-rated cables are available in a variety of different coloured HR PVC sheaths including black, red and white, to accommodate for several applications.

Features and Benefits


  • Conductor stranding is flexible, plain annealed copper

  • Cross sectional area: 0.75 mm²

  • Current rating: 14 A

  • Sheath Colour: White

  • Maximum operating temperature of 105°C

  • Oil resistant with temperatures up to 60°C

  • Suitable for wiring circuits where the alternating test voltage does not exceed 4kV r.m.s for 1 minute.

  • Flame retardant, spread of flame has been tested to BS EN 60332-1-2, VW-1 and FT-1 standards

  • Manufactured within the United Kingdom

What is a Tri-Rated cable?


Tri-rated cable is a type of single core insulated electrical cable (with Class 5 flexibility as rated by British Standard BS EN 60228:2005). Tri-rated cable is also known as BS6231, panel wire or switchgear cable. It is made with flexible plain annealed copper that is covered with an HR PVC (heat resistant polyvinyl chloride) insulation.

The term tri-rated refers to meeting the specifications of three separate standards. These standards are BSI, (The British Standards Institute) UL, (Underwriters Laboratories) and CSA (Canadian Standards Associations).

What applications is Tri Rated cable used?


These tri-rated switchgear cables are commonly used in power switchgear applications, but they can be used in everyday electrical installations with the result of overall higher quality.

Electrical cabinets

Switch control in power switchgear

Relay and instrumentation panels of power switchgear

Internal connectors in rectifier equipment

Motor starters and controllers

Small electrical devices

Industrial electrical installations

Panel building

Approvals


Through the approval of three international standards, our RS PRO tri-rated cable is perfectly suited for equipment installations that require both North America and European wiring regulations and codes of practice.
