Vishay 2 Gang Rotary Conductive Plastic Potentiometer with a 6 mm Dia. Shaft, 50kΩ, ±20%, 0.05W, Linear
- RS Stock No.:
- 504-2706
- Mfr. Part No.:
- P9A2R100FISX1503MA
- Brand:
- Vishay
Bulk discount available
Subtotal (1 unit)*
£22.20
(exc. VAT)
£26.64
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 4 unit(s) shipping from 30 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 1 | £22.20 |
2 - 4 | £17.76 |
5 - 9 | £16.65 |
10 - 24 | £15.98 |
25 + | £15.32 |
*price indicative
- RS Stock No.:
- 504-2706
- Mfr. Part No.:
- P9A2R100FISX1503MA
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Potentiometer Type | Rotary | |
Maximum Resistance | 50kΩ | |
Number of Gangs | 2 | |
Number of Turns | 1 | |
Power Rating | 0.05W | |
Electrical Taper | Linear | |
Element Material | Conductive Plastic | |
Mounting Type | Panel Mount, Through Hole | |
Termination Style | Pin | |
Shaft Length | 20mm | |
Shaft Diameter | 6 mm | |
Tolerance | ±20% | |
Series | P9A | |
Actuator Type | Flatted Shaft | |
Select all | ||
---|---|---|
Brand Vishay | ||
Potentiometer Type Rotary | ||
Maximum Resistance 50kΩ | ||
Number of Gangs 2 | ||
Number of Turns 1 | ||
Power Rating 0.05W | ||
Electrical Taper Linear | ||
Element Material Conductive Plastic | ||
Mounting Type Panel Mount, Through Hole | ||
Termination Style Pin | ||
Shaft Length 20mm | ||
Shaft Diameter 6 mm | ||
Tolerance ±20% | ||
Series P9A | ||
Actuator Type Flatted Shaft | ||
9mm 100mW P9A Series
Conductive Plastic
Ultra Compact (Extra miniature module size)
Multiple Assemblies (single and dual modules)
Linear and Logarithmic options
Locating peg without detent
PC pins, 2.5mm between gangs
Ultra Compact (Extra miniature module size)
Multiple Assemblies (single and dual modules)
Linear and Logarithmic options
Locating peg without detent
PC pins, 2.5mm between gangs
