TE Connectivity TW 25 kΩ Rotary Potentiometer 1-Turns 1-Gang Panel Mount

RS Stock No.:: 136-1812
Mfr. Part No.:: TW1253KA
Brand:: TE Connectivity

TE Connectivity TW 25 kΩ Rotary Potentiometer 1-Turns 1-Gang Panel Mount

Subtotal (1 box of 500 units)*

£4,321.00

(exc. VAT)

£5,185.00

(inc. VAT)

FREE delivery for orders over £50.00

Temporarily out of stock

Shipping from 06 August 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Box*
500 +	£8.642	£4,321.00

*price indicative

RS Stock No.:: 136-1812
Mfr. Part No.:: TW1253KA
Brand:: TE Connectivity

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	TE Connectivity
	Potentiometer Type	Rotary
	Product Type	Potentiometer
	Maximum Resistance	25kΩ
	Number of Gangs	1
	Shaft Diameter	6.35mm
	Number of Turns	1
	Power Rating	1W
	Electrical Taper	Linear
	Element Material	Wirewound
	Mount Type	Panel Mount
	Termination Style	Solder Lug
	Shaft Length	15mm
	Pin Count	3
	Minimum Operating Temperature	-55°C
	Adjustment Type	Side
	Maximum Operating Temperature	125°C
	Length	42.5mm
	Standards/Approvals	RoHS
	Tolerance ±	10%
	Series	TW
	Actuator Type	Round Shaft
	Mounting Hole Diameter	10 mm

	Select all
	Brand TE Connectivity
	Potentiometer Type Rotary
	Product Type Potentiometer
	Maximum Resistance 25kΩ
	Number of Gangs 1
	Shaft Diameter 6.35mm
	Number of Turns 1
	Power Rating 1W
	Electrical Taper Linear
	Element Material Wirewound
	Mount Type Panel Mount
	Termination Style Solder Lug
	Shaft Length 15mm
	Pin Count 3
	Minimum Operating Temperature -55°C
	Adjustment Type Side
	Maximum Operating Temperature 125°C
	Length 42.5mm
	Standards/Approvals RoHS
	Tolerance ± 10%
	Series TW
	Actuator Type Round Shaft
	Mounting Hole Diameter 10 mm

Datasheet

23mm TW Series Potentiometers

The 23mm high power wire-wound potentiometers from TE where designed to be used in a high power control environment. They are brilliant build quality with a stainless steel shaft and a rugged hard plastic casing. The potentiometers in this series are all standard with ±10% tolerance. They also have a life cycle of 10,000 operations. The 23mm series are panel mount for ease of use.

The series of 23mm TW are all rotary potentiometers. This means the shaft is housed by a knob. Turning the shaft will operate the wiper and adjust the resistance.
