MPN

TE Connectivity 23 10 kΩ Rotary Potentiometer 1-Turns 1-Gang Panel Mount

RS Stock No.:: 135-4434
Mfr. Part No.:: 1624213-2
Brand:: TE Connectivity

TE Connectivity 23 10 kΩ Rotary Potentiometer 1-Turns 1-Gang Panel Mount

Subtotal (1 box of 100 units)*

£604.80

(exc. VAT)

£725.80

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

1,100 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Box*
100 +	£6.048	£604.80

*price indicative

RS Stock No.:: 135-4434
Mfr. Part No.:: 1624213-2
Brand:: TE Connectivity

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	TE Connectivity
	Potentiometer Type	Rotary
	Product Type	Potentiometer
	Maximum Resistance	10kΩ
	Number of Gangs	1
	Shaft Diameter	6.35mm
	Number of Turns	1
	Power Rating	0.2W
	Electrical Taper	Logarithmic
	Element Material	Carbon
	Mount Type	Panel Mount
	Termination Style	Solder Lug
	Shaft Length	50mm
	Adjustment Type	Side
	Pin Count	3
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	70°C
	Height	25.2mm
	Depth	21.6mm
	Standards/Approvals	RoHS
	Length	60.7mm
	Tolerance ±	20%
	Series	23
	Actuator Type	Round Shaft

	Select all
	Brand TE Connectivity
	Potentiometer Type Rotary
	Product Type Potentiometer
	Maximum Resistance 10kΩ
	Number of Gangs 1
	Shaft Diameter 6.35mm
	Number of Turns 1
	Power Rating 0.2W
	Electrical Taper Logarithmic
	Element Material Carbon
	Mount Type Panel Mount
	Termination Style Solder Lug
	Shaft Length 50mm
	Adjustment Type Side
	Pin Count 3
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 70°C
	Height 25.2mm
	Depth 21.6mm
	Standards/Approvals RoHS
	Length 60.7mm
	Tolerance ± 20%
	Series 23
	Actuator Type Round Shaft

Datasheet

50mm Long Shaft, Rotary, Switched and Dual Potentiometers

TE Connectivity brings you a range of premium quality rotary potentiometers. With their brilliant build quality, they also boast a carbon element material and are panel mounted. They’re built with ruggedness in mind and are housed in an aluminium housing. Not to mention they’re solder lug termination to make it easier for a panel mount.
