Vishay P16 1kΩ Rotary Potentiometer 1-Gang Panel Mount, P16NM102MAB15CV1D
- RS Stock No.:
- 298-382
- Mfr. Part No.:
- P16NM102MAB15CV1D
- Brand:
- Vishay
Subtotal (1 unit)*
£21.52
(exc. VAT)
£25.82
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 40 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £21.52 |
*price indicative
- RS Stock No.:
- 298-382
- Mfr. Part No.:
- P16NM102MAB15CV1D
- Brand:
- Vishay
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Potentiometer Type | Rotary | |
| Maximum Resistance | 1kΩ | |
| Number of Gangs | 1 | |
| Number of Turns | 1 | |
| Power Rating | 1W | |
| Electrical Taper | Linear | |
| Element Material | Cermet | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Shaft Length | 9.4mm | |
| Shaft Diameter | 16 mm | |
| Tolerance | ±20% | |
| Series | P16 | |
| Actuator Type | Round Shaft | |
Select all | ||
|---|---|---|
Brand Vishay | ||
Potentiometer Type Rotary | ||
Maximum Resistance 1kΩ | ||
Number of Gangs 1 | ||
Number of Turns 1 | ||
Power Rating 1W | ||
Electrical Taper Linear | ||
Element Material Cermet | ||
Mounting Type Panel Mount | ||
Termination Style Solder Lug | ||
Shaft Length 9.4mm | ||
Shaft Diameter 16 mm | ||
Tolerance ±20% | ||
Series P16 | ||
Actuator Type Round Shaft | ||
