Nichicon 120 μF Surface Mount Polymer Capacitor, 50V
- RS Stock No.:
- 243-7200
- Mfr. Part No.:
- PCR1H121MCL2GS
- Brand:
- Nichicon
Bulk discount available
Subtotal (1 tape of 5 units)*
£12.05
(exc. VAT)
£14.45
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1,440 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 45 | £2.41 | £12.05 |
| 50 - 195 | £2.324 | £11.62 |
| 200 + | £2.19 | £10.95 |
*price indicative
- RS Stock No.:
- 243-7200
- Mfr. Part No.:
- PCR1H121MCL2GS
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Product Type | Polymer Capacitor | |
| Technology | Polymer, Electrolytic | |
| Capacitance | 120μF | |
| Voltage | 50V | |
| Mount Type | Surface Mount | |
| Lead Pitch | 3.2mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 8 x 12 mm | |
| Length | 11.9mm | |
| Depth | 8.3mm | |
| Height | 8.3mm | |
| Series | PCR | |
| Electrolyte Type | Solid | |
| Lifetime | 4000 h | |
| Automotive Standard | AEC-Q200 | |
| Leakage Current | 180μA | |
| Dissipation Factor | 0.08% | |
| Ripple Current | 2900mA | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 8mm | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Product Type Polymer Capacitor | ||
Technology Polymer, Electrolytic | ||
Capacitance 120μF | ||
Voltage 50V | ||
Mount Type Surface Mount | ||
Lead Pitch 3.2mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 8 x 12 mm | ||
Length 11.9mm | ||
Depth 8.3mm | ||
Height 8.3mm | ||
Series PCR | ||
Electrolyte Type Solid | ||
Lifetime 4000 h | ||
Automotive Standard AEC-Q200 | ||
Leakage Current 180μA | ||
Dissipation Factor 0.08% | ||
Ripple Current 2900mA | ||
Minimum Operating Temperature -55°C | ||
Diameter 8mm | ||
- COO (Country of Origin):
- JP
The Nichicon's PCR series is chip type polymer capacitor have high reliability, low ESR and provides high ripple current, high voltage.
High reliability, High voltage (to 80V)
Low ESR, High ripple current
Long life of 4000 hours at 125°C
SMD type : Lead free reflow soldering condition at 260°C peak complete correspondence
Compliant to the RoHS directive (2011/65/EU,(EU)2015/863)
ESR after
