Nichicon 180 μF Surface Mount Polymer Capacitor, 50 V
- RS Stock No.:
- 243-7201
- Mfr. Part No.:
- PCR1H181MCL1GS
- Brand:
- Nichicon
Subtotal (1 reel of 400 units)*
£471.20
(exc. VAT)
£565.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 400 unit(s) shipping from 30 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 400 + | £1.178 | £471.20 |
*price indicative
- RS Stock No.:
- 243-7201
- Mfr. Part No.:
- PCR1H181MCL1GS
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Technology | Polymer, Electrolytic | |
| Product Type | Polymer Capacitor | |
| Capacitance | 180μF | |
| Voltage | 50 V | |
| Mount Type | Surface Mount | |
| Lead Pitch | 4.6mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 10 x 12.7 mm | |
| Length | 12.6mm | |
| Height | 10.3mm | |
| Series | PCR | |
| Depth | 10.3mm | |
| Electrolyte Type | Solid | |
| Automotive Standard | AEC-Q200 | |
| Ripple Current | 3500mA | |
| Lifetime | 4000 h | |
| Diameter | 10 mm | |
| Leakage Current | 270μA | |
| Minimum Operating Temperature | -55°C | |
| Dissipation Factor | 0.08% | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Technology Polymer, Electrolytic | ||
Product Type Polymer Capacitor | ||
Capacitance 180μF | ||
Voltage 50 V | ||
Mount Type Surface Mount | ||
Lead Pitch 4.6mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 10 x 12.7 mm | ||
Length 12.6mm | ||
Height 10.3mm | ||
Series PCR | ||
Depth 10.3mm | ||
Electrolyte Type Solid | ||
Automotive Standard AEC-Q200 | ||
Ripple Current 3500mA | ||
Lifetime 4000 h | ||
Diameter 10 mm | ||
Leakage Current 270μA | ||
Minimum Operating Temperature -55°C | ||
Dissipation Factor 0.08% | ||
- COO (Country of Origin):
- JP
The Nichicon's PCR series is chip type polymer capacitor have high reliability, low ESR and provides high ripple current, high voltage.
High reliability, High voltage (to 80V)
Low ESR, High ripple current
Long life of 4000 hours at 125°C
SMD type : Lead free reflow soldering condition at 260°C peak complete correspondence
Compliant to the RoHS directive (2011/65/EU,(EU)2015/863)
ESR after
