Panasonic 330μF Through Hole Polymer Capacitor, 35V dc
- RS Stock No.:
- 210-5957
- Mfr. Part No.:
- EEHZS1V331P
- Brand:
- Panasonic
Subtotal (1 reel of 400 units)*
£300.40
(exc. VAT)
£360.40
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 400 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
400 + | £0.751 | £300.40 |
*price indicative
- RS Stock No.:
- 210-5957
- Mfr. Part No.:
- EEHZS1V331P
- Brand:
- Panasonic
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Panasonic | |
Technology | Hybrid | |
Capacitance | 330µF | |
Voltage | 35V dc | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 14mΩ | |
Tolerance | ±20% | |
Length | 12.5mm | |
Maximum Operating Temperature | +125°C | |
Dimensions | 10 x 12.5mm | |
Series | ZS | |
Ripple Current | 3.5A | |
Lifetime | 4000h | |
Leakage Current | 115 μA | |
Polarised | Polar | |
Diameter | 10mm | |
Dissipation Factor | 12% | |
Minimum Operating Temperature | -55°C | |
Select all | ||
---|---|---|
Brand Panasonic | ||
Technology Hybrid | ||
Capacitance 330µF | ||
Voltage 35V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 14mΩ | ||
Tolerance ±20% | ||
Length 12.5mm | ||
Maximum Operating Temperature +125°C | ||
Dimensions 10 x 12.5mm | ||
Series ZS | ||
Ripple Current 3.5A | ||
Lifetime 4000h | ||
Leakage Current 115 μA | ||
Polarised Polar | ||
Diameter 10mm | ||
Dissipation Factor 12% | ||
Minimum Operating Temperature -55°C | ||
