Panasonic 470 μF Surface Mount Polymer Capacitor, 25V dc

RS Stock No.:: 210-5945
Mfr. Part No.:: EEHZS1E471P
Brand:: Panasonic

Panasonic 470 μF Surface Mount Polymer Capacitor, 25V dc

Subtotal (1 tape of 2 units)*

£3.32

(exc. VAT)

£3.98

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

284 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Tape*
2 +	£1.66	£3.32

*price indicative

Precision Performance with Panasonic – Aluminium Capacitors for Demanding Applications

Panasonic Aluminium Capacitors offer reliability, low ESR, and excellent ripple current handling in compact designs. They are built for long service life. Perfect for automotive, industrial, and power applications, these components maintain consistent performance in real-world operating environments.

Shop Here

RS Stock No.:: 210-5945
Mfr. Part No.:: EEHZS1E471P
Brand:: Panasonic

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Panasonic
	Product Type	Polymer Capacitor
	Technology	Hybrid
	Capacitance	470μF
	Voltage	25V dc
	Mount Type	Surface Mount
	Polarity	Polar
	Tolerance	±20 %
	Maximum Operating Temperature	135°C
	Dimensions	10 x 12.5 mm
	Height	11mm
	Length	12.5mm
	Series	ZS
	Electrolyte Type	Hybrid
	Ripple Current	3.5A
	Leakage Current	117.5μA
	Lifetime	4000 h
	Diameter	10mm
	Dissipation Factor	14%
	Automotive Standard	AEC-Q200
	Minimum Operating Temperature	-55°C

	Select all
	Brand Panasonic
	Product Type Polymer Capacitor
	Technology Hybrid
	Capacitance 470μF
	Voltage 25V dc
	Mount Type Surface Mount
	Polarity Polar
	Tolerance ±20 %
	Maximum Operating Temperature 135°C
	Dimensions 10 x 12.5 mm
	Height 11mm
	Length 12.5mm
	Series ZS
	Electrolyte Type Hybrid
	Ripple Current 3.5A
	Leakage Current 117.5μA
	Lifetime 4000 h
	Diameter 10mm
	Dissipation Factor 14%
	Automotive Standard AEC-Q200
	Minimum Operating Temperature -55°C

Datasheet - EEHZS1E471P

COO (Country of Origin):: JP

Panasonic Series ZS Polymer Capacitor, 470 μF Capacitance, 25V DC Voltage - EEHZS1E471P

This polymer capacitor is a hybrid component designed for surface mounting applications. With a capacitance Value of 470μF and a voltage rating of 25 V DC, this low ESR capacitor is suitable for a variety of electronic applications. Measuring 10 x 12.5mm, it operates efficiently in temperature ranges from -55°C to +135°C, making it a reliable choice for demanding environments.

Features & Benefits

• Hybrid technology combines benefits of conductive polymers and aluminium
• Low equivalent series resistance (14 mΩ) enhances performance
• Polarised design caters to specific circuit requirements
• Tolerance of ±20% accommodates standard variations in capacitance
• High ripple current handling (3.5 A) supports robust applications
• Long lifetime of 4000 hours ensures durability in operations

Applications

• Used in automation and control circuits
• Essential for power supply filters in electronics
• Utilised in DC-DC converters for improved efficiency
• Effective in audio equipment for filtering signals
• Suitable for use in automotive for enhanced reliability

What is the significance of the low ESR in this component?

The low ESR (14 mΩ) reduces energy loss during operation, which increases efficiency and enhances overall performance. This feature is critical for applications where power conservation is essential.

How does the temperature rating affect the longevity of this component?

Operating effectively at temperatures ranging from -55°C to +135°C ensures that it can handle extreme conditions without degradation, thereby extending its operational lifespan to 4000 hours.

In what type of circuits is a polarised capacitor necessary?

Polarised capacitors are Crucial in circuits where directionality matters, such as in DC power supplies, where they prevent incorrect installation that could lead to failure or damage.

What are the implications of a ±20% tolerance in capacitance?

A tolerance of ±20% indicates the allowable variation from the nominal capacitance of 470μF, ensuring compatibility in applications where precise values are not critical but overall functionality is maintained.

How does the ripple current specification impact performance?

A ripple current rating of 3.5 A signifies the maximum alternating current the capacitor can handle, promoting stability and reliability in high-frequency applications without overheating or failure.
