Panasonic 105μF Surface Mount Polymer Capacitor, 6.3V dc
- RS Stock No.:
- 210-4882
- Mfr. Part No.:
- 6TPS150MUD
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 tape of 5 units)*
£4.84
(exc. VAT)
£5.81
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,460 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 20 | £0.968 | £4.84 |
| 25 - 95 | £0.778 | £3.89 |
| 100 - 495 | £0.68 | £3.40 |
| 500 - 995 | £0.634 | £3.17 |
| 1000 + | £0.548 | £2.74 |
*price indicative
- RS Stock No.:
- 210-4882
- Mfr. Part No.:
- 6TPS150MUD
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Technology | Polymer | |
| Capacitance | 105µF | |
| Dielectric Material Family | Tantalum | |
| Voltage | 6.3V dc | |
| Mounting Type | Surface Mount | |
| Package/Case | B1S | |
| Equivalent Series Resistance | 30mΩ | |
| Tolerance | ±20% | |
| Length | 3.5mm | |
| Depth | 1.1mm | |
| Maximum Operating Temperature | +105°C | |
| Height | 1.2mm | |
| Dimensions | 3.5 x 2.8 x 1.1mm | |
| Series | TPS | |
| Electrolyte Type | Solid | |
| Ripple Current | 1.4A | |
| Automotive Standard | POSCAP | |
| Minimum Operating Temperature | -55°C | |
| Polarised | Polar | |
| Diameter | 2.2mm | |
| Leakage Current | 94.5 μA | |
| Lifetime | 2000h | |
| Dissipation Factor | 0.1% | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Technology Polymer | ||
Capacitance 105µF | ||
Dielectric Material Family Tantalum | ||
Voltage 6.3V dc | ||
Mounting Type Surface Mount | ||
Package/Case B1S | ||
Equivalent Series Resistance 30mΩ | ||
Tolerance ±20% | ||
Length 3.5mm | ||
Depth 1.1mm | ||
Maximum Operating Temperature +105°C | ||
Height 1.2mm | ||
Dimensions 3.5 x 2.8 x 1.1mm | ||
Series TPS | ||
Electrolyte Type Solid | ||
Ripple Current 1.4A | ||
Automotive Standard POSCAP | ||
Minimum Operating Temperature -55°C | ||
Polarised Polar | ||
Diameter 2.2mm | ||
Leakage Current 94.5 μA | ||
Lifetime 2000h | ||
Dissipation Factor 0.1% | ||
The Panasonic Conductive Polymer Tantalum solid capacitors with surface mounting type works with a rated voltage ranges from 2.5 V to 6.3 V.
153 μF to 330 μF rated capacitance range
±20% capacitance tolerance
–55°C to +105°C category temperature range
±20% capacitance tolerance
–55°C to +105°C category temperature range
