KEMET 22μF Through Hole Polymer Capacitor, 25V dc
- RS Stock No.:
- 173-9288
- Mfr. Part No.:
- A758EK226M1EAAE050
- Brand:
- KEMET
Bulk discount available
Subtotal (1 bag of 1000 units)*
£122.00
(exc. VAT)
£146.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
---|---|---|
1000 - 2000 | £0.122 | £122.00 |
3000 + | £0.112 | £112.00 |
*price indicative
- RS Stock No.:
- 173-9288
- Mfr. Part No.:
- A758EK226M1EAAE050
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Technology | Electrolytic | |
Capacitance | 22µF | |
Dielectric Material Family | Aluminium | |
Voltage | 25V dc | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 50mΩ | |
Lead Pitch | 2.5mm | |
Tolerance | ±20% | |
Height | 8mm | |
Maximum Operating Temperature | +105°C | |
Dimensions | 6.3 (Dia) x 8mm | |
Series | A758 | |
Electrolyte Type | Solid | |
Diameter | 6.3mm | |
Leakage Current | 120 μA | |
Dissipation Factor | 10% | |
Polarised | Polar | |
Ripple Current | 2A | |
Lifetime | 5000h | |
Minimum Operating Temperature | -55°C | |
Select all | ||
---|---|---|
Brand KEMET | ||
Technology Electrolytic | ||
Capacitance 22µF | ||
Dielectric Material Family Aluminium | ||
Voltage 25V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 50mΩ | ||
Lead Pitch 2.5mm | ||
Tolerance ±20% | ||
Height 8mm | ||
Maximum Operating Temperature +105°C | ||
Dimensions 6.3 (Dia) x 8mm | ||
Series A758 | ||
Electrolyte Type Solid | ||
Diameter 6.3mm | ||
Leakage Current 120 μA | ||
Dissipation Factor 10% | ||
Polarised Polar | ||
Ripple Current 2A | ||
Lifetime 5000h | ||
Minimum Operating Temperature -55°C | ||
- COO (Country of Origin):
- CN
KEMETs A758 Single-Ended Conductive Polymer Aluminum Solid Electrolytic Capacitors offer longer life and greater stability across a wide range of temperatures. The A758 highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties, is able to withstand higher ripple currents during normal operation. The A758 is ideally suited for industrial and commercial applications. Typical applications include mobile phone chargers, adapters (laptop power supplies) and medical equipment.
Through-hole form factor
Miniature
Low impedance
High ripple current
Long life
105°C/5,000 hours
Miniature
Low impedance
High ripple current
Long life
105°C/5,000 hours
