Wurth Elektronik 680μF Through Hole Polymer Capacitor, 6.3V dc
- RS Stock No.:
- 163-7166
- Mfr. Part No.:
- 870135174004
- Brand:
- Wurth Elektronik
Subtotal (1 box of 800 units)*
£357.60
(exc. VAT)
£428.80
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
---|---|---|
800 + | £0.447 | £357.60 |
*price indicative
- RS Stock No.:
- 163-7166
- Mfr. Part No.:
- 870135174004
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Technology | Polymer | |
Capacitance | 680µF | |
Voltage | 6.3V dc | |
Dielectric Material Family | Aluminium | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 9mΩ | |
Lead Pitch | 3.5mm | |
Tolerance | ±20% | |
Maximum Operating Temperature | +125°C | |
Height | 8mm | |
Dimensions | 8 (Dia) x 8mm | |
Series | WCAP-PTHT | |
Ripple Current | 6.1A | |
Minimum Operating Temperature | -55°C | |
Dissipation Factor | 8% | |
Diameter | 8mm | |
Leakage Current | 428 μA | |
Lifetime | 2000h | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Technology Polymer | ||
Capacitance 680µF | ||
Voltage 6.3V dc | ||
Dielectric Material Family Aluminium | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 9mΩ | ||
Lead Pitch 3.5mm | ||
Tolerance ±20% | ||
Maximum Operating Temperature +125°C | ||
Height 8mm | ||
Dimensions 8 (Dia) x 8mm | ||
Series WCAP-PTHT | ||
Ripple Current 6.1A | ||
Minimum Operating Temperature -55°C | ||
Dissipation Factor 8% | ||
Diameter 8mm | ||
Leakage Current 428 μA | ||
Lifetime 2000h | ||
- COO (Country of Origin):
- CN
Wurth Elektronik General Purpose WCAP-PTHT Capacitor Series 125°C
Aluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are:
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
WCAP-PTHT Series are high temperature polymer electrolytic capacitors
Low ESR at high frequency range
Operating temperature: -55°C to +125°C
Load life of 2000h @ +125°C
Wave soldering is recommended
Low ESR at high frequency range
Operating temperature: -55°C to +125°C
Load life of 2000h @ +125°C
Wave soldering is recommended
