Wurth Elektronik 180μF Through Hole Polymer Capacitor, 25V dc
- RS Stock No.:
- 163-7133
- Mfr. Part No.:
- 870025575006
- Brand:
- Wurth Elektronik
Subtotal (1 box of 600 units)*
£340.20
(exc. VAT)
£408.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 29 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
---|---|---|
600 + | £0.567 | £340.20 |
*price indicative
- RS Stock No.:
- 163-7133
- Mfr. Part No.:
- 870025575006
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Technology | Polymer | |
Capacitance | 180µF | |
Dielectric Material Family | Aluminium | |
Voltage | 25V dc | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 20mΩ | |
Lead Pitch | 5mm | |
Tolerance | ±20% | |
Length | 12.5mm | |
Maximum Operating Temperature | +105°C | |
Height | 12.5mm | |
Dimensions | 10 (Dia) x 12.5mm | |
Series | WCAP-PTG5 | |
Lifetime | 2000h | |
Leakage Current | 900 μA | |
Polarised | Polar | |
Diameter | 10mm | |
Dissipation Factor | 8% | |
Ripple Current | 4.9A | |
Minimum Operating Temperature | -55°C | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Technology Polymer | ||
Capacitance 180µF | ||
Dielectric Material Family Aluminium | ||
Voltage 25V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 20mΩ | ||
Lead Pitch 5mm | ||
Tolerance ±20% | ||
Length 12.5mm | ||
Maximum Operating Temperature +105°C | ||
Height 12.5mm | ||
Dimensions 10 (Dia) x 12.5mm | ||
Series WCAP-PTG5 | ||
Lifetime 2000h | ||
Leakage Current 900 μA | ||
Polarised Polar | ||
Diameter 10mm | ||
Dissipation Factor 8% | ||
Ripple Current 4.9A | ||
Minimum Operating Temperature -55°C | ||
- COO (Country of Origin):
- CN
Wurth Elektronik General Purpose WCAP-PTG5 Capacitor Series 105°C
Aluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are:
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
High permissible ripple current due to lower ESR at high frequency range
Higher long term stability and expected life
No dry out phenomenon due to solid conductive polymer
Features and Benefits
Low ESR at high frequency range
High permissible ripple current
Load life of 2000 h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering is recommended
High permissible ripple current
Load life of 2000 h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering is recommended
Solid Radial 105°C
