Panasonic 120 μF Surface Polymer Capacitor, 50V
- RS Stock No.:
- 434-017
- Mfr. Part No.:
- EEHZV1H121P
- Brand:
- Panasonic
Bulk discount available
View bulk pricing optionsSubtotal (1 pack of 5 units)*
£12.09
(exc. VAT)
£14.51
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1,000 unit(s) shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 45 | £2.418 | £12.09 |
| 50 - 245 | £1.958 | £9.79 |
| 250 - 495 | £1.498 | £7.49 |
| 500 + | £1.332 | £6.66 |
*price indicative
- RS Stock No.:
- 434-017
- Mfr. Part No.:
- EEHZV1H121P
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Product Type | Polymer Capacitor | |
| Technology | Aluminium Electrolytic | |
| Capacitance | 120μF | |
| Voltage | 50V | |
| Mount Type | Surface | |
| Package/Case | Surface Mount | |
| Polarity | Negative | |
| Lead Pitch | 4.6mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 135°C | |
| Dimensions | 10 x 10.2 mm | |
| Series | ZV | |
| Height | 10.2mm | |
| Electrolyte Type | Hybrid Aluminium Electrolytic | |
| Dissipation Factor | 0.1% | |
| Diameter | 10mm | |
| Lifetime | 4000 h | |
| Anti Vibration | No | |
| Minimum Operating Temperature | -55°C | |
| Ripple Current | 4.3A | |
| Automotive Standard | AEC-Q200 | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Product Type Polymer Capacitor | ||
Technology Aluminium Electrolytic | ||
Capacitance 120μF | ||
Voltage 50V | ||
Mount Type Surface | ||
Package/Case Surface Mount | ||
Polarity Negative | ||
Lead Pitch 4.6mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 135°C | ||
Dimensions 10 x 10.2 mm | ||
Series ZV | ||
Height 10.2mm | ||
Electrolyte Type Hybrid Aluminium Electrolytic | ||
Dissipation Factor 0.1% | ||
Diameter 10mm | ||
Lifetime 4000 h | ||
Anti Vibration No | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 4.3A | ||
Automotive Standard AEC-Q200 | ||
- COO (Country of Origin):
- JP
Panasonic Polymer Capacitor, 120μF Capacitance, 50V Voltage - EEHZV1H121P
This polymer capacitor is a surface-mount aluminium electrolytic device designed for demanding electronic and automotive environments. It provides decoupling and smoothing functionality in power management circuits and is intended for use where elevated temperature tolerance and long operational life are required. The component is polarised and supplied in a taped package for automated assembly.
Features and Benefits:
• Rated for 50V operation enabling higher-voltage rail support
• Capacitance of 120 μF for effective bulk energy storage
• Low ESR permitting 4.3 A ripple handling for power stability
• Wide temperature tolerance to 135 °C for hot-board reliability
• Long service life of 4000h supporting extended maintenance intervals
• Low leakage current of 60 μA reducing standby losses
• Capacitance of 120 μF for effective bulk energy storage
• Low ESR permitting 4.3 A ripple handling for power stability
• Wide temperature tolerance to 135 °C for hot-board reliability
• Long service life of 4000h supporting extended maintenance intervals
• Low leakage current of 60 μA reducing standby losses
Applications
• Suitable for automotive power-supply filtering in control modules
• Ideal for industrial automation DC-bus decoupling tasks
• Used with motor-drive electronics requiring high ripple endurance
• Can be used for voltage-smoothing in power-conversion assemblies
• Used for backup-power conditioning in embedded systems
• Ideal for industrial automation DC-bus decoupling tasks
• Used with motor-drive electronics requiring high ripple endurance
• Can be used for voltage-smoothing in power-conversion assemblies
• Used for backup-power conditioning in embedded systems
What mounting method is required for this component?
It is intended for surface-mount placement and supplied in a taped format for pick-and-place assembly.
How does tolerance affect circuit design with this capacitor?
The device has a ±20% tolerance, so designers should account for potential variation when calculating required capacitance margins.
What environmental extremes can the component withstand?
It operates down to -55 °C and up to 135 °C, making it suitable for wide-range thermal conditions.
How does the capacitor conform to automotive quality needs?
It meets AEC‑Q200 criteria for components used in vehicle electronics, addressing reliability requirements for automotive applications.
What physical constraints should be considered for board layout?
The package measures 10 x 10.2mm with a 10mm diameter and 10.2mm height and a lead pitch of 4.6 mm, which should be accommodated in footprint planning.
